Help CenterAgricultural Machinery Hydraulic High Quality Offset Disc Harrow
Related Products
-
Trailed Hydraulic Heavy Duty Disc HarrowUS$ 500 - 7,000MOQ: 1 Set -
Tractor Light Duty Disk HarrowUS$ 200 - 3,000MOQ: 1 Set
-
China New Compact Tractor Disc Harrow With Low PriceUS$ 1,000 - 10,000MOQ: 1 Set
-
Agricultural Disc Harrow for Sale With Best QualityUS$ 1,000 - 10,000MOQ: 1 Set
-
Farm Hydraulic Disc Harrow With Best PriceUS$ 1,000 - 10,000MOQ: 1 Set
5: disc harrow Linkage : Trailed
6: disc harrow Export: EU;North America ;South America; North Africa etc..
powerful enterprises spare parts for disc harrow with high quality offset disc harrow
The series heavy-duty off-set disc harrows are mainly used for cleaning away stuble of plants before tillage,or crushing clods after tillage on uncultivated land and in sticky heavy clay soil fields,they can also be used as a plough for primary tillage in dry culdtivated fields.
The series produced are all fitted with hydraulic rubber wheel for transportation.
It is easy to be transported and change direction on the edge of fields.
Specifications:
| Model | Unit | 1BZ-1.8 | 1BZ-2.2 | 1BZ-2.5 | 1BZ-3.0 | 1BZ-3.4 |
| Overall dimension | cm | 480*200*134 | 482*244*134 | 532*288*134 | 532*332*134 | 582*376*134 |
| Weight | kg | 1050-1100 | 1250-1300 | 1380-1430 | 1500-1550 | 1650-1700 |
| Working width | m | 1.8 | 2.0 | 2.5 | 3.0 | 3.4 |
| Working depth | cm | 20 | ||||
| Blade spacing | mm | 230 | ||||
| No of disc | pc | 16 | 20 | 24 | 28 | 32 |
| Dia.of disc | mm | 660 | ||||
| Transport clearance | mm | >160 | ||||
| Producivity | ha/h | 1.1 | 1.3 | 1.4 | 1.7 | 1.9 |
| Matched power | kw | 44-55 | 52.9-66.2 | 55-73.5 | 58.8-88 | 66.2-100 |
| Linkage | Trailed | |||||
Provincial department of commerce organization of agriculture academic exchanges,
The only visit enterprise in Yucheng City.
