steel coil SLITTING machine 0.5-6.0 x 1600

Loading Trolley Car

1. Loading Capacity: 20 Tons

2. Lifting Height: 600 mm

 Hydraulic Decoiler

1. Loading Capacity: 20 Tons

2. Expansion Range: 60 mm

3. Expansion Grades: ø460mm-ø520mm, ø620mm, ø770mm

Feeding & Flattening

1. Feeding Roller (2pcs): ø150mm x 1600mm, GCr 15

2. Flattening Roller (5pcs): ø150mm x 1600mm, GCr 15

3. Motor: 37KW

Slitting Machine

1. Slitting blade shaft: ø220mm x 1600mm, 40Cr

2. Blade Diameter: ø380mm

3. Motor: 90KW

Hydraulic Recoiler

1. Loading Capacity: 20 Tons

2. Expansion Range: 28mm (ø480mm-ø508mm)

3. Motor Power: 132 KW DCMotor

Hydraulic System

1. Oil Tank Volume: 500 kg

2. Hydraulic Power Grade: Grade E

3. Vane Pump: 15KW motor

            Oil output: 30ML

            Nominal Pressure: 70kg/cm²

            Max. Pressure: 140kg/cm²

4. Hydraulic parts made in Taiwan

Electronic System

1. Power Supply: 380V, 3 phases, Voltage fluctuates within +10%

2. Control Power: 220V AC / 24V DC

3. PLC Control
