High quality portable type Particles tester for filter material
Product description
N(c)-6 Portable particle counter is researched adopting light-blocking method theory
(shading type), used in real-time monitoring for oil pollution particles of hydraulic system.
At the same time, because of its built-in the precision metering pump, which can realize
offline (bottle) test of low viscosity oil.
Product Application
N(c)-6 Portable particle counter is widely applied in aviation, aerospace, electric power,
petroleum, chemical industry, transportation, ports, metallurgy, machinery, automobile
manufacturing and so on, in these fields implement solid particles pollution testing in the
hydraulic oil, lubricating oil, transformer oil (insulating oil), turbine oil, gear oil, engine oil,
aviation kerosene, water-based hydraulic oil etc., and particle impurities detection in the
organic liquid and polymer solution.
Product Characteristic
♦ Adopting light blockage method theory,ensure the resolution and accuracy.
♦ Import precision power unit can realize the constant sample injection speed and accurate volume control.
♦ LCD display,one-click operation is simple and convenient, standard serial
RS232 interface is controlled by host computer.
♦ Built-in mini-printer, the test results print out directly.
♦ Built-in NAS1638, ISO4406 standard, sample pollution level can be provided;
and can built-in the standards according to the customer’s requirements (such
as GJB420A - 96 and GJB420B -2006 etc.).
♦ Demarcated and calibrated according to ISO4402 or GB / 18854-2002
(ISO11171:1999, JJG066-95).
♦ Equipped with USB storage function.
♦ Import and export adopts the quick connector.
Technical data
Light source: Semiconductor laser
Pressure: 0~0.6Mpa
Test range: 1μm~400μm
The temperature of tested sample:<50°C
Sensitivity: 1μm(ISO4402)or 4μm(C)
Test repeatability:<5% (count value)
(ISO11171:GB/T18854-2002)
Test accuracy: ±0.5 Pollution level
Measurement channel: Six arbitrary setting particles channels
Power: 24V,4A 5V,6A
Sampling rate: 20mL/min
Sampling accuracy: ±3%
Environmental temperature:10°C~40°C
Interface type: Stainless steel quick connector; inlet and outlet outer diameter φ 6, inner diameter φ 4 nylon hose assemblies
Apparatus volume:400(L)×350(W)×210(H)
♦The testing centrer- hydraulic filter performance evaluation :
ISO 2941 Verification of collapse/burst resistance
ISO 2942 Verification of fabrication integrity and determination of the first bubble point
ISO 2943 Verification of material compatibility with fluids
ISO 3723 Method for end load testing
ISO 3724 Verification of flow fatigue characteristics
ISO 3968 Evaluation of pressure drop versus flow characteristics
ISO 16889 Multi-Pass method for evaluating filtration performance
