2015 hot product low price stainless steel TRF series industrial suction filter

2015 hot product low price stainless steel TRF series industrial suction filter

Product  Introduction

TRF suction-return filters are used for hydrostatic transmission, under all the motion

conditions, when the flow rate of return oil is always higher than the flow rate of the

hydraulic pump output.Through full-flow filtration of filter element, meet the highest

cleanliness rating requirements. The product is suction-return oil filtration in one,

can filter the suction oil completely,so that contaminants cannot enter the hydraulic

 pump. Through the full-flow filtration of the system return oil line, protecting the hydraulic

pump from particles contamination.

Product  characteristics

TRF series filters consist of the housing and filter element, also has check valve (0.5bar),

two-way ball valve with transparent hose, filter element, pressure safety valve (2.5bar),

emergency suction valve for protecting filter element, pressure control valve (0.5bar),

oil returning port, suction oil mouth of supply pump, pressure clogging indicator port,

and vacuum clogging indicator port etc.

Housing material

Housing material: steel and aluminum alloy

Filter cover: Aluminum alloy

Seals

Perbunan (= NBR) ; Viton (= FPM)

Filter element

Filter medium material

High strength carbon steel skeleton

Type of connection

Inch threaded connection
