80um Filtration Stock TF-800X80F-Y Hydraulic Oil Suction Filters

80um filtration stock TF-800X80F-Y hydraulic oil suction filters

Product  Introduction

The TF series filters can be installed at the pump suction port ,on the top,at the side or in the bottom of the tank,

filter bowl is immersed below the level of the tank, the filter head is outside the tank. This filter has these features:

novel design, convenient installation, high oil-passing capacity, and small resistance, filter element cleaning and

 replacement  is convenient.                                                                                                                                 Product  Characteristics

Filter basic construction

The cover and the lower housing of the TF series filters adopt threaded connection; filter bowl is spun on the

lower housing. This filter is with check valve, by-pass valve and clogging indicator, when filter element is

withdrawn for washing or replaced;the check valve will close automatically to stop oil flowing out from the tank.

Housing material

Filter cover material: High strength  plastic end cap

Filter bowl material: High strength composite membrane aluminum tube

Filter element

Filter medium material

High strength carbon steel skeleton

Order example

Technical Data

 Four Series Leading Products                                                                                                                                      “Hydraulic System Cleaning & Filtration Device”,

                                           “Complete Hydraulic Filters”,

                                           “Hydraulic System Accessories ”,

                                           “Pump Valve Components”.

Company Honor

♦ China's Quality Recognized Top Ten Well-known Filter Brand

Cooperative Partner

• Manufacturer
• Competitive price can be offered
• Optimum paper folding
• Large dust holding capacity
• Good temperature resistance
• Good anti-humidity performance
• Environmental Friendly
• OEM & ODM Customized is accepted
• On-time delivery
• Durable and reliable
• Ecnomical,practical,and easy to install

If you are interested in our products, pls feel free to contact me directly,

I will give you the fast response and satisfied service.
