DFFILTRI Stock Thread Connection 80um Suction Filters TF-160X80L

Name: DFFILTRI Stock Thread Connection 80um Suction Filters TF-160X80L
Brand: DFFILTRI
Availability: InStock

FOB Price

US$ 1 - 300 / Unit

5 Units(Min. Order)

Port QINGDAO DALIAN TIANJIN SHANGHAI GUANGZHOU NINGBO
Payment TermsT/T L/C D/P D/A Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China		Brand Name	DFFILTRI
Model Number	TF-160*80L

Product Description

Product Introduction

The cover and the lower housing of the TF series filters adopt threaded connection; filter bowl is spun on the lower housing. This filter is with check valve, by-pass valve and clogging indicator, when filter element is with drawn for washing or replaced;the check valve will close automatically to stop oil flowing out from the tank.

The TF series filters can be installed at the pump suction port ,on the top,at the side or in the bottom of the tank,filter bowl is immersed below the level of the tank, the filter head is outside the tank. This filter has these features:novel design, convenient installation, high oil-passing capacity, and small resistance, filter element cleaning and replacement is convenient.

*SPECIFICATIONS FOR TF-16080L hydraulic oil suction filter**
Product material	Housing material	Filter cover:high strength plastic end cap Filter bowl:high strength composite membrane aluminum tube
	Seals	Perbunan(=NBR)	Viton(=FPM)(Customizable)
	Filter medium	High strength carbon steel skeleton
Main performance parameters	Nominal flow rate	L/min	160
	Type of connection	Threaded connnection
	Dia	mm	20
	Cracking pressure of the bypass valve	bar	Setting 0.2
	Filtration rating	um	80
	Type of indicator	Y=ZKF-II clogging indicator ≤DC24V
	Weight	Kg	0.55

Certifications

Our Delivery

Transport of large trucks to the seaport

International transport cooperation

Our Packing

Packaging
Packaging Details	The normal package is carton,case(Size: LWH).or pack it according to customers special request.

Packaging
Packaging Details	The normal package is carton,case(Size: LWH).or pack it according to customers special request.
