Zu-h/qu-h Pressure Line Filter With High Quality1.Filtering and high precision
2.Service life is long
1. Product introduction
ZU-H, QU-H series filters are installed on pressure pipeline of the hydraulic system, there are these characteristics: high pressure resistance, high accuracy & multi-function etc., which can meet various requirements from the customer through installing different components. Series filter adopts glass fiber filter material, with high filtration rating, big flow rate capacity, low original pressure loss, large contamination retention capacity etc. advantages.
2. Product characteristics
Filter basic construction
ZU-H, QU-H filter is composed of the top cover and spin-on housing.
2.1 Housing material
Top cover material: Ductile cast iron
Filter bowl material: Carbon steel
2.2 Seals
Perbunan (=NBR) (-30~+120°C); Viton=FPM(-20~+200°C)
2.3 Filter element
Filter medium material
High strength carbon steel skeleton
2.4 Optional accessories
Electric clogging indicator: CS-V
By-pass valve (Setting 6bar)
2.5 Type of connection (chosen according to the filter type)
Metric thread connection; Inch threaded connection; Flanged connection
2.6 Symbols
3. Type selection and technical data
3.1 Order example
3.2 Technical Data
Note: 1) if inch threaded connection is needed, please contact us;
2) * represents filtration ratin
4. Mounting Size
4.1 Threaded connection
Note: When flow rate is 10L/min, oil outlet thread should be chosen M18×1.5; when flow rate is 25L/min, outlet thread should be chosen M22×1.5,
which belong to the special ordering, the model should be ZUT-H10×*P;ZUT-H25×*P;* represents filtration rating.
4.2 Flangede connection
Note: * represents filtration rating.
4.3 Connection flange is processed as per the folowing dimension:
4.4 Plated connection
4.5 Inverted tubular connection
4.6 Inverted flange connection
4.7 Inverted flange connection A
4.8 Inverted flange connection B
4.9 Inverted plated connection
4.10 Connection falnges are processed as per the following dimensions
About us:
we own world advanced production equipment and produce high-quality products of
international standard with brand-new industrial conceptand strong technical forces.
We firmly believe we will become your trusted partner.
