Replace Hydac LF Hydraulic Pressure Oil Filter
1. Product Introduction
LFZ series filters are installed on the medium pressure line, with these characteristics of high filtration accuracy, small flow rate resistance,low initial pressure loss, high dirt-holding capacity, which can meet the various requirements from the customers (can replace Hydac LF series).
Type Selection and Technical Data
Order example
Technical Data
| Model | Nomal Flow Rate (L/min) | Nominal Pressure | Mounting Size | Filtration Rating ( μm ) |
Type of Indicator |
Cracking Pressure of the Bypass Valve (bar)
|
Seals |
Model of Filter Element |
Weight (kg) | |
| LFZ | 30 | 100 bar | G ½ |
Optional 3,5,10,20,30...
βx(c) optional 75,100,200,1000, in accordance with ISO 16889 |
A=Steel Plug
B=CM-03
C=CM-05
D=CM-08 |
T--Setting 6 bar
X--Custom-made
N--Without Bypas Valve |
V=FPM
W=NBR |
DF0030D* |
0.13 | |
| 60 | G ¾ | DF0060D* |
0.2 | |||||||
| 110 | G ¾ | DF0110D* |
0.33 | |||||||
| 160 | G 1¼ | DF0160D* |
0.6 | |||||||
| 240 | G 1¼ |
DF0240D* |
0.8 | |||||||
| 330 | G 1½ |
DF0330D* |
1.5 | |||||||
| 660 | G 1½ |
DF0660D*
|
3 | |||||||
Note: If any other requriements, please consult us; * represents filtration rating.
About Us
♦DFFILTRI was founded in 1995, since then we devoted ourselves to research, develop and produce many kinds of hydraulic filters, air filters, hydraulic system accessories, cleaning and filtration equipments,pump valve components. DFFILTRI is our brand, which enjoys high
popularity and it has successfully achieved the position both in China and across the world.
♦DFFILTER filtration technology testing center covers a total area of 450 square meters,
of which, clean room area of 200 square meters, and cleanliness is up to 100,000 levels.
The centre undertakes filtration technology inspection and testing for in-house science
research,production and industry service.
♦On-line particle counter of BETAB-HIAC/POYCO type (8000A/8000S) provided by
HIAC/POYCO company in USA, and its supporting machine"Multi-pass test" and
"single-pass test" implements ISO16889 new standard and other international
standards perfectly.
♦Testing center also has the developed equiment for filter performance testing, which can
make the comprehensive examination for filter element/cartridge performance. These can
insure that company’s filter with high capacity, long life, high reliable in full compliance with
our customer's requirement.
Our Advantage
1) Adopting the new industrial concept
2) Establishing world-class R&D and testing center
3) Possessing powerful technical force and R&D strength
4) Having the world's advanced production equipment
5) Producing high quality products that comply with international and national standards
6) Outstanding quality products to meet or exceed customer's expectation
7) Professional and wholehearted pre-market after-sales service
|
Qualification and Honor of DFFILTRI
|
Contact Us
|
Xinxiang Dongfeng Filter Technology Co., Ltd. Add: No.42, West of Beigan Road, Xinxiang, Henan, China (mainland) Telephone: 86-373-2677957 Mobile Phone: +86-18737320955 Fax: 86-373-2634868 |
