Home > Products > Hydraulic gear pump > CBT-8.8/3.6 hydraulic gear pump for log splitter
CBT-8.8/3.6 hydraulic gear pump for log splitter
- 2000 Piece / Pieces per Month
- Shanghai or Qingdao
- Credit Card PayPal
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Shandong, China | Brand Name: | FORWARD | Model Number: | CBT-8.8/3.6 |
Theory: | Rotary Pump | Structure: | Gear Pump | Usage: | Oil |
Power: | Hydraulic | Standard or Nonstandard: | Standard | Fuel: | Diesel |
Pressure: | High Pressure | Application: | Other, construction machine, agriculture machine,hydraulic system |
Product Description
The CBT series gear pump consists of a big displacement, low pressure pump and a small displacement, high pressure pump, a check valve as well as a relief valve. When working at the pressure lower than the relief pressure, both big and small pump supply volume. When working at a high pressure, only small pump supplies volume, which highly reduces the power consumption. The CBT pump is widely used in log splitter, press, machine tools. Each item will be 100% tested before shipment.
model | FLOW @ 1800RPM L/min(GPM) | Displacement ml/r(in3/r) | pressure(Mpa) | Speed(RPM) | Dimension | ||||
high pre | low pre | unload | work | L(mm) | L1 | L2 | |||
CBN- 6.3/2.1 | 30(8) | 2.1 | 6.3 | Range: 2.8-6.3, preset: 4.5 | 21 | 3600 | 154.7 | 94.4 | 61.6 |
CBN-6.3/3.0 | 32.5(8.5) | 3 | 6.3 | 158.2 | 97.9 | 61.6 | |||
CBN-6.3/3.6 | 34.5(9) | 3.6 | 6.3 | 159.9 | 99.6 | 61.6 | |||
CBN-8.8/2.1 | 38(10) | 2.1 | 8.8 | 162.7 | 102.4 | 69.6 | |||
CBN-8.8/3.0 | 40(10.5) | 3 | 8.8 | 166.2 | 105.9 | 69.6 | |||
CBN-8.8/3.6 | 42(11) | 3.6 | 8.8 | 167.9 | 107.9 | 69.6 | |||
CBN-8.8/4.2 | 44(11.5) | 4.2 | 8.8 | 170.2 | 109.9 | 69.6 | |||
CBN- 10.9/2.1 | 46(12) | 2.1 | 10.9 | 170.2 | 109.9 | 77.1 | |||
CBN-10.9/3.0 | 48(12.5) | 3 | 10.9 | 173.7 | 113.4 | 77.1 | |||
CBN-10.9/3.6 | 50(13) | 3.6 | 10.9 | 175.4 | 115.1 | 77.1 | |||
CBN-10.9/4.2 | 52(13.5) | 4.2 | 10.9 | 177.4 | 117.4 | 77.1 | |||
CBN-13/4.2 | 62(16.4) | 4.2 | 13 | 184.7 | 122.1 | 84.1 |
Usually each pump with plastic bag will be put into one Box,6 boxes into one Carton,finally suitable qty cartons on one Wooden Pallet.Of course we can pack as customer's requiry,Customize packing.
Samples will be packed with carton and delivered by Express; orders will be packed with pallet,and delivered by sea or by air.
1.Each pump will be tested before shipping.
2.1- year- warranty.
3.Professional workers from Forward R&D department will offer you great technical support.
Q: What is our main application?
A: such as Hydraulic system,Agriculture machine,Constraction machine,Automobile,and so on.
Q: What is Payment Terms?
Big order: 50% as deposit, the balance before shipment; Small order /sample order: T/T 100% payment in advance;
Q: Can I Mark My Own Brand On The Pump?
A: Yes. Full order can be marked your brand and code if you want.
Contact person: Selina
Skype: chenna615
Ph./WhatsApp:86-13706310773
Tel/Fax: 86-631-5653475
