Specifications
SJPL-G HIGH SPEED PLASTIC TAPE EXTRUSION MACHINESJPL-G HIGH SPEED PLASTIC TAPE EXTRUSION MACHINE
SJPL-G Plastic tape extrusion stretching line is specially designed for PP and HDPE with high quality and excellent performance.
Perfect tape quality lowest consumption best economic benefit
Available:Woven sack chemical bag foods bag cement bag leno bag jumbo bag geo-textile tarpaulin carpet backing tape artificial grass tape
High Precise T-Die
Simulating extrusion and one-off process molding by CNC guarantee the tape quality.
Intelligentized Control System
The function of data saving, fault alarm can be controlled by touch screen with simple operation.
Haul-Off System
Special design stable flow device and water remove system create the condition for high speed production.
High Speed Winder
By inverter controlled stable tension winding units, the bobbin is formed with equal tension and smooth surface. Speed can be reached 550m/min.
Direct Connection Motor
The motor is directly connected with the extruder, the gear box and connection shaft is removed to save the maintenance requirements and also reduce the power consumption.
(THIS DEVICE IS OPTIONAL)
MAIN TECHNICAL PARAMETERS:
| Model | SJPL-G100×33-1100×10 |
SJPL-G110×33-1500×10 |
Max. extrusion volume |
500kg/h |
650kg/h |
Extruder motor power |
90kw |
110kw |
Screw diameter |
100mm |
110mm |
Die lip length |
1100mm |
1500mm |
Max. production speed |
550m/min |
550m/min |
Number of winder |
170spindles |
210spindles |
Overall dimensions (L×W×H) |
34000×3700×3600mm |
35000×3900×3600mm |
* Related with the melt pump | ||
**Related with the fiberness of raw material and finished products | ||
Standard Equipment |
Optional Device |
Granulate loader |
Other extruders |
Specification and dimensions are subject to change without prior notice.
We always adhere to the designing idea of high quality,high efficiency & low consumption,and protect the environment and promote sustained development.
