Magnatic Damping Compensator Cross Line Laser Level SY528

Features:

• Magnetic damping compensator to ensure more quick self-leveling time;
• Bright and high visible laser beams with 10mw or 15mw laser diodes;
• If the unit exceed the self-leveling range, the laser line will be shut off with warning signal;
• The unit will emit one horizontal and four vertical lines with plum dot. The 4 vertical lines will be acrossed over the ceiling at 90º;
• With indoor/outdoor swith function (Laser detector can be used for outdoor operation);
• Built-in locking system to lock the compensator when in transportation to avoid vibration;
• Charge connector function;
• Main unit can rotate 360º on the base with 1º scale instruction;

Specifications:

• Laser fan angle: ≥ 130°
• Laser safety class: Class II
• Lines accuracy: ±1mm / 10m
• Self leveling range: ±4°
• Self leveling time: ≤ 5 seconds
• Operating range: 15m
• Operating time: >10 hours
