Specifications
Cross Line Laser level With High Precision SRG502 Cross Line Laser level With High Precision SRG502
Specifications
Lasers:5 dots, 1V-1H
Horizontal line accuracy: ≤ ± 3mm /10m
Vertical line accuracy: ≤ ± 3mm /10m
Up beam accuracy: ≤4mm /10m
Operation time: >Down beam accuracy: ≤6mm /10m
Left right and front 3 dots leveling accuracy: ≤4mm /10m
Superposition accuracy(Dots & lines): ≤ 5mm /10m
Self-leveling range: 4°±1°
Dot Working range: ≤30m
Line Working range: ≤10m; >25m with Laser detector
Diode power: 635nm±5nm, Class 2M
Operation time: >Working time: ≥7hs
Dimensions(LxWxH): 116x69x112mm
Self-Leveling with magnetic pendulum.
Features
Small size unit and can be hold in hand easily
High visibility laser line .full orientations,high stability,handeling
5beams & 1V,1H(cross over the ceiling) ,laser lines have a large fan angle (150°)
Laser lines & laser dots can be combined or independent for operation
Operation time: >Laser line or laser dots blink if the unit is out of the self-leveling range
Center locking system to lock the pendulum while in transportation to avoid the vibration(patent).
In /Outdoor function for option.(working with laser detector).
Tilting fuction(turn off the warning when the laser exceed the leveling range by the lock)
Compact size and handling housing with elastomeric rubber for easy carrying.
