Horticulture Hedge Trimmer CY-7510

Specifications

Hand Type Hedge Trimmer
Easy operation,780mm for blade length,displacement 22.5cc.
Metal is SS for blade.19 teeth.2-stroke

Model:CY-7510

Type:Hand

Measure:100*28.5*23cm

Net Weight:5.3kg

Engine:132F/ 22.5

Transfer type:Automatic centrifugation

Reduction Ratio:5.12

Blade Lenghth:780mm

Clutch touch:3600-3800

Max cutting:35mm

Productivity:more than 200 m2/h

Teeth: 19teeth single side



1E34F

Type:1-cylinder,2-stroke,air-cooled

bore and stroke:32*28mm

Max. power:0.68KW

Rated Power:0.65KW

Rated Speed:8500r/min

High Speed:10000r/min

Displacement:22.5cc

Fuel Tank:0.6L

Start System:Recoil

Ignition System:non-contact Transistorized

Fuel Oil:less than 610g/kwh

Carburetor:Pump-film

Measure:20*20*17.5cm

Net Weight:2.5kg
