Specifications
50Hz Portable Generator 5KW Portable GeneratorAC Portable Generator
16L Portable Generator
3P Portable Generator
Generator
Product:
-- 50Hz Portable Generator; 5KW Portable Generator; 400V/230V Portable Generator
-- 3 Phase Portable Generator; AC Portable Generator
-- Diesel Portable Generator; Diesel Engine Portable Generator
-- Engine Power Portable Generator; Fuel Power Portable Generator
-- Small Portable Generator; Silent Portable Generator
-- 171KG Portable Generator; 16L Portable Generator
-- Hand Start or Key Start Portable Generator
-- Good Portable Generator
Technical Specification:
Generators |
CP6700T |
CP6700T3 |
||
Generator Rated Frequency |
50Hz |
60Hz |
50Hz |
60Hz |
Generator Rated Output |
4.2Kw |
5Kw |
5Kw |
6Kw |
Generator Rated Voltage (AC) |
230V |
240V/120V |
400V/230V |
416V/240V |
Generator Rated Current (AC) |
21.7A |
22.9A/45.8A |
7.2A |
8.3A |
Generator Rated Speed |
3000 r/min |
3600 r/min |
3000 r/min |
3600 r/min |
Generator Phase |
Single Phase |
Three Phase |
||
Generator Power Factor (cosf) |
1 |
0.8 Lag in Phase |
||
Generator Exiciting System |
Transistor, Self-Exciting Constant Voltage (AVR) |
|||
Generator DC Output |
12V/8.3A |
0 |
||
Generator Connecting System |
Tajpered Joint |
|||
Generator Gross Weight |
171KG |
|||
Generator Overall Dimension |
950×520×740 |
|||
Generator Engine |
CP186FA |
|||
Generator Engine Type |
4 Stroke; Single Cylinder; Air Cooled Direct Injection; Diesel Engine |
|||
Generator Cont.Output |
5.83KW |
6.4KW |
5.83KW |
6.4KW |
Bore×Stroke |
86×72 |
|||
Generator Displacement |
0.418L |
|||
Generator Cooling System |
Forced Air Cooled |
|||
Generator Lubrication System |
Pressure Combined with Splashing |
|||
Generator Lubrication Capacity |
1.65L |
|||
Generator Starting System |
Electric Start |
|||
Generator Fuel |
0# in Summer Diesel Fuel; 10# in Winter |
|||
Generator Fuel Tank Capacity |
16L |
|||
|
Generator Low Oil Pressure Generator Warning System |
With |
|||
Generator Color |
Red, Green, Blue, Yellow, Orange, Etc |
|||
Generator FOB Price |
Pending |
Pending |
Pending |
Pending |
Generator Package |
Common Carton Box or Wooden Box or As Required |
|||
Generator Delivery Time |
15 Days after Order Confirmed |
|||
DGenerator elivery Way |
By Sea; By Land; By Air |
|||
Generator Payment Term |
T/T; L/C; Paypale; Western Union; Cash |
|||
Generator MOQ |
10 Sets |
|||
Generator Sample Order |
Accepted |
|||
OEM Service |
Accepted |
|||
Product’s Feature:
Portable Generator Compact in Structure; Portable Generator Nice in Appearance
Portable Generator Lighter in Weight; Portable Generator Smaller in Size
Portable Generator with Lower Noise; Portable Generator with Lower Fuel Consumption
Portable Generator with Higher Output; Portable Generator with Lower Vibration
Portable Generator with Smooth Running; Portable Generator with Reliable Performance
Portable Generator Easy to Start; Portable Generator Easy to Maintence
Company Introduction:
Chongqing Camel Power Machinery Co., Ltd (CCPMC) is a manufacturer of agricultural machinery and an export base in Chongqing City in south of China.
Our factory specializes in producing high quality, medium and small power 4 stroke air cooled diesel engine and water cooled diesel engines, walking tractors, diesel portable generators and diesel water pump sets.
Our well known brand“CAMEO”gained the honor of “The Best Export Brands of Chongqing for Priority Cultivation and Development in 2006-2007” from Chongqing Municipal Government.
Under the management of MBA degree members, national grade internal combustion engine experts and generator experts and with the support of advanced production and inspection methods as well as a perfect product development and quality guarantee system, CCPMC passed ISO9001:2000 certification and the test of Thai Industrial Standard from Thai Industrial Standards Institute and Ministry of Industry of Thailand. It’s sound worldwide marketing and satisfactory after-sales service network makes our products more and more popular.
Now our annual production capacity of high and medium grade diesel engines, diesel water pumps, and diesel portable generators reaches 200,000 units.
CCPMC insists on the theory that “quality is eternal object; perfect product based on conscientious hard work”.
With exclusive technology and years’ manufacture experience, CCPMC hopes to cooperate with friends both at home and abroad for mutual benefit.
