Farm machinery in hot seller

Specifications

Thorough threshing
Clear separation
Low grain breakage
High grain cleanness
Good maneuverability in the wet & soft field



main specification
Type			Track self-propelled harvester
Model			4LZ-2.0
Havesting Width		mm	1800
Feed		kg/s	2.0
Diese Engine	Model	kw	42
	Power	HP	58
	Rotate Speed	R/min	2800
Average oil consumption per hectare		kg/ha	20-23
working  productivity		ha/h	0.2-0.47
weight	big  tank/0.7m3	kg	2510 (small rice tank),2590(big rice tank)
Dimension LxWxH(mm)		mm	5245x2690x2675
Header	Reel type		eccentic, spring toothed
	Reel Diameter	mm	¢1000
	No.of bars		5
	Auger type		Spiral toothed
	Auger Diameter	mm	¢480
	Clearance between Auger fingers and bottom platform	mm	11-15(adjustable)
	Cutter knife travel	mm	76.2
Conveyer	Type		rake toothed band (rake toothed chain)
	linear speed of rake teeth movement	m/s	5
Roller	Type		axial flow,rasp-bar
	Diameter	mm	¢550(adjustable)
	Length	mm	1332
	Speed of rotation	R/min	912
Concave	type		grid
	angle		238
	clerance between concave and rasp-bar	mm	7~19
Sieves	Type		Double sieves+blower+re-thresher
	top sieve/area	m2	0.81
	bottom sieve/area	m2	0.92
	tail sieve area	m2	0.22
Fan	Type		centrifugal,volute
	Diameter	mm	¢360
Vertical auger	Diameter	mm	¢125
Horizontal auger	Diameter	mm	¢125
Grain Tank		m3	0.3
Chassis	Type		Rubber track
	Track	mm	350×90×46
	Gear box		(6+2) geared gearbox
	Drving speed	m/s(km/h)	0.476(1.71)~2.635(9.49)
Re-thresher	Type		plank toothed
	Rotor diameter/lentgth	mm	180/1475
Unloading			Sacked & Auto unloading



Hot Sale in liulin brand !! Mini Rice and Wheat Grain Combine Harvester- 2M harvest width with 82HP with Big grain tank

                          (Mobile: 0086-18968527259 )



Our factory is one of biggest and professional producer for self-propelled combine harvester in China. with more than 20 years experience in manufacture combine harvester and gain high reputation from our customers all over the world. we make sure to supply excellent combine harvester with high quality and competitive price. what's more, the best after-sale service is also avialable.





1. Brief introduce combine harvester



1) our gear box is :6+2   ( hangzhou yunnei brand, china famours brand)



YZ21-B series gearbox with large output power, strong carrying capacity, reliable steering and braking, compact   structure and easy to operate. Which is adaptable for below 2.5m high-power combine harvester .

Main technical specifications:
Model: YZ21-B-type

gear type: integral-type (3 +1) × 2
Structural weight: 165 kg

clutch pulley diameter: ¢ 220
Clutch Pulley Model: B-type

Clutch: 3 often combined with Friction
Brake Type: Wet disc brake oil on paper substrates

Lubricating Oil : NO.68, anti-wear hydraulic oil
Steering Brake Type: Single Linkage, unilateral drive shaft of the maximum output torque 1500N.M



(2) two levers operation : easy to perate and more economical.







3) Large power ( we fix kunming-yunnei brand,china famous brand)









4)China famour brand, hangzhou yunnei-brand track







5) unloading auguer by hydraulic





 2. Working Show







3.Company Show
