metric bronze bushing oilite bearing sliding bush
metric bronze bushing oilite bearing sliding bush
metric bronze bushing/bronze bushing material/oilite bronze bushing/oilite bushing/sliding bush
- Feature
Bimetal bushing is based on steel and sintered with CuPb10Sn10 or CuSn6Zn6Pb3 as a lining layer.
The strongest type of bimetal bushings and widely applicated in so many fields. This type has the best performance within the range of Cu-Pb alloy construcured bushing. Therefor it has a wide application and is mostly suitable for where is middle speed and high impact etc.
- Layers sturcture of bimetal bushing
- Technical Date
Material | JF-800 | Steel+Bronze(CuSn10Pb10) |
JF850 | Steel+ Bronze(CuSn6Zn6Pb3) | |
JF-720 | Steel+ Bronze(CuSn4Pb24) | |
JF-20 | Steel+ Bronze(AlSn20Cu) | |
JF700 | Steel+ Bronze(CuPb30) | |
Load capacity |
| 150N/mm2 |
Speed limit | Oil lubricating | 2.5m/s |
Dry Friction | 0.4m/s | |
PV value limit | Oil lubricating | 10N/mm2.m/s |
Dry friction | 2.8 N/mm2.m/s | |
Mating axis required | Hardness | >=48~53HRC |
Roughness | Ra=0.16~0.63 | |
Friction coef |
| 0.05-0.22 |
Working temperature max. |
| 200°C |
- Production flow
- Size list
- Typical Application
other beairngs
- Factory informtion
Admin Office
workshops
Inspection
- We are supplying full lines of slide bushings:
SF-1(du) oilless bearing bushing (PTFE Composite) |
SF-2(dx) slide bearing bushing (POM Composite) |
FB090(FB090G) bronze bushing |
FB092 bronze bushing |
JDB,JFB solid graphite lubricating bushing |
JF bi-metal bushing |
FU sintered bronze or iron bushing |
FZ POM/Al/Cu ball cage retainer |
- ISO/TS16949 certification
