Working principle
Wood pellet extrusion machine is the briquette machinery,which using the theory of screw extrusion to process the coal powder into a predeter mined shape with a certain intensity. after the coal powder poured into machine chamber,it bears tremendous pressure.With the help of all kinds of shaped molds,it will be shaped into certain shapes. Now, our factory has developed the different style machine including the double-head and four-head coal rod machine.It not only improve production capacity largely,but also give the buyers more choices.
Features
1. The pellet mill is made of wear-resistant material thus having a long service life.
2. Ready-to-get raw materiasl like paddy straw, sunflower stalk, forestry wastes, wood chips, and many other wastes or solid powder material.
3. Able to change new die and rollers fast and conveniently.
4. Small and light weight which make it widely used in home,small farm,and light industrial.
5.Visibility of the material during pelleting is the best way to fix problems timely.
6. Environmental friendly; energy-saving and low noise.
7. Widely applied to small-sized factory, plant and individual home.
Pictures
Parameter
Model |
Power |
Capacity |
Diameter of pellet |
Weight |
Dimension |
SKJ350 |
30kw |
300-500kg/h |
2-30mm |
950kg |
1650x1000x1500mm |
SKJ450 |
37kw |
500-700kg/h |
2-30mm |
1100kg |
1800x1100x1650mm |
SKJ550 |
45kw |
800-1000kg/h |
2-30mm |
1700kg |
2000x1000x1700mm |
SKJ-800 |
90kw |
1500-2000kg/h |
2-30mm |
4250kg |
2100x1050x2250mm |
SKJ-1000 |
110kw |
2000-3000kg/h |
2-30mm |
5200kg |
2100x1050x2250mm |
Final product
How to choose a suitable briquette presss machine
1. What’s the raw material?
As different materials match different machines, So pls tell us what’s the raw material.
2. The moisture of raw material ?
The moisture determines whether dryer is needed in the process.
3. The size of raw material ?
It should be crushed if the size is too big.
4. Capacity you need ?
Different capacity match different models of machine. the smaller the capacity is, the simpler the process will be.
