Home > Products > Dryer Equipment > factory supplier large output sugar fluid bed dryer
factory supplier large output sugar fluid bed dryer
- 15 Set / Sets per Month
- Qingdao Shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Rotary Drying Equipment | |
| Place of Origin | Henan, China | Brand Name | Telon | |
| Model Number | TL-1000x10000 | Voltage | 380v | |
| Power(W) | 3-75kw | Dimension(L*W*H) | Depend on your requirements | |
| Weight | 2-100tons, 5.6 t | Certification | ISO, CE | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.Dryer for sand, slag, vinasse etc.2.High quality,efficiency
3.Widely usage
4.Series options
5.Competitive price.
Introduction:
The rotary dryer mainly consists of rotor, shed plate, transmission device, support device, seal ring, and other spare parts. The rotary dryer has the advantages of reasonable structure, excellent manufacture, high output, low energy consumption, convenient operation and so on.
The rotary dryer is widely applied in mining, metallurgy, building materials, chemistry and other industries, mainly stoving mineral powder, slag, clay, limestone, lignite and other materials.
Operating principle:
Rotary dryer is a contact-type internal heating conduction machine. It is usually used in chemical industries, mining, metallurgy, and other industries. There are many types of the rotation drum dryer. According to the rollers' numbers, it can be divided into single, twin-drum, multiple-drum dryer. By operating pressure, it can be divided into two kinds: ordinary pressure and vacuum drum dryer. Classified by the fabric membrane form, it usually can be divided into top feeding, immersion, and spray dryer.
| Model (mm) | Inclination (%) | Rotate speed (r/min) | Air inlet temperature (°C) | Power (kw) | Production capacity(t/h) | Weight (t) |
| Φ600x6000 | 3-5 | 3-8 | ≤700 | 3 | 0.5-1.5 | 2.9 |
| Φ800x8000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.0 | 3.5 |
| Φ800x10000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.5 | 4.5 |
| Φ1000x10000 | 3-5 | 3-8 | ≤700 | 5.5 | 1.0-3.5 | 5.6 |
| Φ1200x10000 | 3-5 | 3-8 | ≤700 | 7.5 | 1.8-5 | 14.5 |
| Φ1200x12000 | 3-5 | 3-8 | ≤700 | 11 | 2-6 | 14.8 |
| Φ1500x12000 | 3-5 | 2-6 | ≤800 | 15 | 3.5-9 | 17.8 |
| Φ1800x12000 | 3-5 | 2-6 | ≤800 | 18 | 5-12 | 25 |
| Φ2200x12000 | 3-5 | 1.5-6 | ≤800 | 18.5 | 6-15 | 33 |
| Φ2200x18000 | 3-5 | 1.5-6 | ≤800 | 22 | 10-18 | 53.8 |
| Φ2200x20000 | 3-5 | 1.5-6 | ≤800 | 30 | 12-20 | 56 |
| Φ2400x20000 | 3-5 | 1.5-5 | ≤800 | 37 | 18-30 | 60 |
| Φ3000x20000 | 3-5 | 1.5-5 | ≤800 | 55 | 25-35 | 78 |
| Φ3000x25000 | 3-5 | 1.5-5 | ≤800 | 75 | 32-40 | 104.9 |
Pictures:
