Home > Auto, Motorcycle Parts & Accessories > Auto Parts > Wheel Hub, Rim & Spoke > Truck Wheel With INMETRO
US$ 20 - 70
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Material:
Steel
Diameter:
25" - 28"
Finishing:
Silver
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Material
Steel
Finishing
Silver
Truck Model
Foton
Brand Name
BAOTA
Model Number
22.5X8.25
Specifications
TRUCK WHEELFULL SIZES
INMETRO CERTIFICATE
TRUCK WHEEL
FULL SIZES
INMETRO CERTIFICATE
| Wheel Size | No. of Bolt Holes | Bolt Hole DIA.(mm) | Bolt Hole Type | P.C.D.(mm) | C.B.D.(mm) | Offset(mm) |
| 17.5X6.00 | 5 | 29 | 1X45° | 203.2 | 146 | 115 |
| 5 | 32 | SR22 | 208 | 150 | 120 | |
| 6 | 20.5 / 21.5 | 1X45° | 205 | 161 | 125 | |
| 6 | 32 | SR22 | 222.25 | 164 | 135 | |
| 8 | 26 | 1X45° | 275 | 221 | 134 | |
| 10 | 26 | 1X45° | 225 | 176 | 133 | |
| 17.5X6.75 | 6 | 20.5 / 21.5 | 1X45° | 205 | 161 | 125 |
| 6 | 32 | SR22 | 222.25 | 164 | 135 | |
| 8 | 26 | 1X45° | 275 | 221 | 134 | |
| 10 | 26 | 1X45° | 225 | 176 | 133 | |
| 19.5X6.75 | 6 | 32 | SR22 | 222.25 | 164 | 140 |
| 8 | 32 | SR22 | 275 | 214 | 145 | |
| 8 | 26 | 1X45° | 275 | 221 | 154 | |
| 8 | 32 | SR22 | 275 | 221 | 154 | |
| 10 | 27 | SR18 | 225 | 176 | 135 | |
| 10 | 21.5 | SR16 | 225 | 164 | 145 | |
| 10 | 21.5 | SR16 | 225 | 176 | 145 | |
| 19.5X7.50 | 6 | 32 | SR22 | 205 | 164 | 145 |
| 8 | 32 | SR22 | 275 | 214 | 145 | |
| 8 | 26 | 1X45° | 275 | 221 | 152 | |
| 10 | 26 | 1X45° | 285.75 | 220 | 145 | |
| 10 | 26 | 1X45° | 176 | 225 | 152 | |
| 19.5X8.25 | 6 | 20.5 / 21.5 | SR16 | 205 | 161 | 0 |
| 8 | 21.5 | SR16 | 275 | 221 | 90 | |
| 8 | 25.4 | 1X45° | 275 | 221 | 0 | |
| 8 | 26 | 1X45° | 275 | 221 | 146 | |
| 8 | 32 | SR22 | 285 | 221 | 153.5 | |
| 10 | 21 | SR16 | 225 | 176 | 146.5 | |
| 10 | 26 | 1X45° | 225 | 176 | 0 | |
| 10 | 26 | 1X45° | 285.75 | 220 | 146.5 | |
| 19.5X14.00 | 8 | 21.5/24.5 | 1X45° | 275 | 221 | 0 |
| 8 | 25.4/27 | SR18 | 275 | 221 | 120 | |
| 10 | 26 | 1X45° | 285.75 | 220 | 0 | |
| 10 | 26 | 1X45° | 335 | 281 | 0 | |
| 10 | 27 | SR18 | 335 | 281 | 120 | |
| 22.5X6.00 | 6 | 32 | SR22 | 222.25 | 164 | 135 |
| 6 | 21.5 | SR16 | 190 | 140 | 135 | |
| 6 | 21.5 | SR16 | 245 | 202 | 138 | |
| 8 | 32 | SR22 | 275 | 214 | 140 | |
| 8 | 32 | SR22 | 285 | 221 | 135 | |
| 10 | 26 | 1X45° | 225 | 176 | 130 | |
| 22.5X6.75 | 8 | 32 | SR22 | 275 | 214 | 152 |
| 8 | 32 | SR22 | 285 | 221 | 140 | |
| 8 | 26 | 1X45° | 275 | 221 | 140 | |
| 10 | 32 | SR22 | 285.75 | 222 | 140.5 | |
| 10 | 26 | 1X45° | 335 | 281 | 142 | |
| 10 | 27 | SR18 | 335 | 281 | 142 | |
| 22.5X7.50 | 8 | 32 | SR22 | 275 | 214 | 152 |
| 8 | 32 | SR22 | 285 | 221 | 165 | |
| 8 | 26 | 1X45° | 275 | 221 | 158 | |
| 10 | 32 | SR22 | 285.75 | 222 | 165 | |
| 10 | 26 | 1X45° | 335 | 281 | 152 | |
| 10 | 27 | SR18 | 335 | 281 | 152 | |
| 22.5X8.25 | 8 | 32 | SR22 | 275 | 214 | 165/168/169 |
| 8 | 32 | SR22 | 285 | 221 | 165/168/169 | |
| 8 | 26 | 1X45° | 275 | 221 | 165/168/169 | |
| 10 | 26 | 1X45° | 285.75 | 220 | 165/168/169 | |
| 10 | 32 | SR22 | 285.75 | 222 | 165/168/169 | |
| 10 | 27 | SR18 | 335 | 281 | 165/168/169 | |
| 10 | 26 | 1X45° | 335 | 281 | 165/168/169 | |
| 22.5X9.00 | 8 | 32 | SR22 | 275 | 214 | 175 |
| 8 | 32 | SR22 | 285 | 221 | 175 | |
| 8 | 26 | 1X45° | 275 | 221 | 175 | |
| 10 | 26 | 1X45° | 285.75 | 220 | 175 | |
| 10 | 32 | SR22 | 285.75 | 222 | 175 | |
| 10 | 27 | SR18 | 335 | 281 | 175 | |
| 10 | 26 | 1X45° | 335 | 281 | 175 | |
| 22.5X11.75 | 8 | 21.5 | SR16 | 275 | 221 | 0 |
| 8 | 26 | 1X45° | 275 | 221 | 120 | |
| 10 | 26 | 1X45° | 335 | 281 | 120 | |
| 10 | 26 | SR18 | 335 | 281 | 0 | |
| 22.5X14.00 | 8 | 21.5 | SR16 | 275 | 221 | 0 |
| 8 | 26 | 1X45° | 275 | 221 | 0 | |
| 10 | 32 | SR22 | 285.75 | 222 | 60 | |
| 10 | 26 | 1X45° | 285.75 | 220 | 75 | |
| 10 | 26 | 1X45° | 335 | 281 | 120 | |
| 10 | 27 | SR18 | 335 | 281 | 0 | |
| 22.5X16.00 | 8 | 21.5 | SR16 | 275 | 221 | 0 |
| 8 | 26 | 1X45° | 275 | 221 | 0 | |
| 10 | 32 | SR22 | 285.75 | 222 | 60 | |
| 10 | 26 | 1X45° | 285.75 | 220 | 75 | |
| 10 | 26 | 1X45° | 335 | 281 | 120 | |
| 10 | 27 | SR18 | 335 | 281 | 0 | |
| 24.5X8.25 | 8 | 32 | SR22 | 275 | 214 | 169 |
| 8 | 32 | SR22 | 285 | 221 | 165 | |
| 8 | 26 | 1X45° | 275 | 221 | 165 | |
| 10 | 26 | 1X45° | 285.75 | 220 | 165 | |
| 10 | 32 | SR22 | 285.75 | 222 | 169 | |
| 10 | 27 | SR18 | 335 | 281 | 169 | |
| 10 | 26 | 1X45° | 335 | 281 | 169 |
