Agricultural Sprayers for Tractor

Agricultural Sprayers for Tractor thumbnail-1
Agricultural Sprayers for Tractor thumbnail-2
Agricultural Sprayers for Tractor thumbnail-3
Agricultural Sprayers for Tractor thumbnail-4
Agricultural Sprayers for Tractor thumbnail-5
Agricultural Sprayers for Tractor thumbnail-6
Agricultural Sprayers for Tractor photo-1
Agricultural Sprayers for Tractor photo-2
Agricultural Sprayers for Tractor photo-3
Agricultural Sprayers for Tractor photo-4
Agricultural Sprayers for Tractor photo-5
Agricultural Sprayers for Tractor photo-6
US$ 10,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Wheel Tractor, agricultural sprayers for tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Qingdao Henry Industry Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO PORT
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Wheel Tractor, agricultural sprayers for tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 81kw
Certificate Other, ISO9001
Brand Name HR
Model Number 804 AND 1204
Place of Origin Shandong, China
After-sales Service Provided No overseas service provided
agricultural sprayers for tractor
Also can produce Model 354, 404,454, 504, 554, 604, 654, 704, 754, 804,904, 954, 1004 , 1104, 1204, 1354, 1404
four wheel tractor
Beautiful appearance, comfortable operation, optional three cylinder, four cylinder engine, to meet your different needs;


The combination instrument and the automobile electric appliance constitute the switch, the control staff can understand the machine working state at any time, and provide the guarantee for the scientific use of the machine;

Meshing gear shift, gear brake mechanism to ensure that the product is durable.
Also have 20-140hp four wheel tractot ,welcome contact with us.





SPECIFICATION:

 Type

804

904

954

1004

1104

1204-1

Drive type

4*4four-wheel drive

4*4 four-wheel drive

4*4 four-wheel drive

4*4four-wheel drive

4*4 four-wheel drive

4*4 four-wheel drive

 Engine



 Engine Brand

 Yuchai

 Yuchai

 Yuchai

Yuchai

Yuchai

 Yuchai

Fuel tank capacity

140L

140L

140L

140L

140L

140L

Rating power of engine

59/2300

66.2/2300

70/2300

73.5/2300

81/2300

88.2/2300

(L)  Displacement

4/4.578

4/4.578

4/4.578

4/4.834

4/4.837

4/4.837

Air filter type/size

 Oil bath   9.5inch   430m3/h

Torque reserve

36.9%

36.7%

34.5%

33.8%

28.3%

26%

Transmission system



 Max. speed

38.18km/h

38.18km/h

38.18km/h

38.18km/h

38.18km/h

38.18km/h

 Gear position

side position

side position

 side position

side position

side position

 side position

 Hydraulic system



Hydraulic output flow rate (L / MIN)

46

46

46

46

46

46

 Working device



 PTO Speed

760/1000

760/1000

760/1000

760/1000

760/1000

760/1000

Lifting Capacity(610mm)kn

22

22

22

22

22

22

Parameter



Min.operation mass(kg)

 With cab

4105

4105

4105

4105

4105

4105

Without cab

3805

3805

3805

3805

3805

3805

 Rated traction force(N)

18.6

20.8

21.5

22.7

23.5

24.5

tyre size

11.2-24/16.9-34

11.2-24/16.9-34

11.2-24/16.9-34

11.2-24/16.9-34

11.2-24/16.9-34

11.2-24/16.9-34

(options: all these types can Optional for ROPS ,Sunshade,swing drawbar, front/rear ballast)









 agricultural sprayers for tractoragricultural sprayers for tractor

PACKAGE  BY  CONTAINER

agricultural sprayers for tractor



FACTORY SHOW

agricultural sprayers for tractoragricultural sprayers for tractor

Optional tools:

agricultural sprayers for tractor

WHY CHOOSE US





   1. Professional supply with certification: CCC, ISO,CE,DOT  and so on



   2. Perfect quality program.  100% test before delivery



   3. One year guarantee.



   4. OEM cervice.



   5. Creative design team and first class quality equipments.



   6. Design and Producing be customized.



   7. Flexible payment. T/T  L/C D/P,WESTERN UNION be accept.



  BOTA BRAND walking tractor looking for sole agnt from every country and city.
