The combination instrument and the automobile electric appliance constitute the switch, the control staff can understand the machine working state at any time, and provide the guarantee for the scientific use of the machine;
Meshing gear shift, gear brake mechanism to ensure that the product is durable.
Also have 20-140hp four wheel tractot ,welcome contact with us.
SPECIFICATION:
Type | 804 | 904 | 954 | 1004 | 1104 | 1204-1 | |
Drive type | 4*4four-wheel drive | 4*4 four-wheel drive | 4*4 four-wheel drive | 4*4four-wheel drive | 4*4 four-wheel drive | 4*4 four-wheel drive | |
Engine | |||||||
Engine Brand | Yuchai | Yuchai | Yuchai | Yuchai | Yuchai | Yuchai | |
Fuel tank capacity | 140L | 140L | 140L | 140L | 140L | 140L | |
Rating power of engine | 59/2300 | 66.2/2300 | 70/2300 | 73.5/2300 | 81/2300 | 88.2/2300 | |
(L) Displacement | 4/4.578 | 4/4.578 | 4/4.578 | 4/4.834 | 4/4.837 | 4/4.837 | |
Air filter type/size | Oil bath 9.5inch 430m3/h | ||||||
Torque reserve | 36.9% | 36.7% | 34.5% | 33.8% | 28.3% | 26% | |
Transmission system | |||||||
Max. speed | 38.18km/h | 38.18km/h | 38.18km/h | 38.18km/h | 38.18km/h | 38.18km/h | |
Gear position | side position | side position | side position | side position | side position | side position | |
Hydraulic system | |||||||
Hydraulic output flow rate (L / MIN) | 46 | 46 | 46 | 46 | 46 | 46 | |
Working device | |||||||
PTO Speed | 760/1000 | 760/1000 | 760/1000 | 760/1000 | 760/1000 | 760/1000 | |
Lifting Capacity(610mm)kn | 22 | 22 | 22 | 22 | 22 | 22 | |
Parameter | |||||||
Min.operation mass(kg) | With cab | 4105 | 4105 | 4105 | 4105 | 4105 | 4105 |
Without cab | 3805 | 3805 | 3805 | 3805 | 3805 | 3805 | |
Rated traction force(N) | 18.6 | 20.8 | 21.5 | 22.7 | 23.5 | 24.5 | |
tyre size | 11.2-24/16.9-34 | 11.2-24/16.9-34 | 11.2-24/16.9-34 | 11.2-24/16.9-34 | 11.2-24/16.9-34 | 11.2-24/16.9-34 | |
(options: all these types can Optional for ROPS ,Sunshade,swing drawbar, front/rear ballast) | |||||||
PACKAGE BY CONTAINER
FACTORY SHOW
Optional tools:
WHY CHOOSE US
1. Professional supply with certification: CCC, ISO,CE,DOT and so on
2. Perfect quality program. 100% test before delivery
3. One year guarantee.
4. OEM cervice.
5. Creative design team and first class quality equipments.
6. Design and Producing be customized.
7. Flexible payment. T/T L/C D/P,WESTERN UNION be accept.
BOTA BRAND walking tractor looking for sole agnt from every country and city.
