four wheel tractor
Beautiful appearance, comfortable operation, optional three cylinder, four cylinder engine, to meet your different needs;
The combination instrument and the automobile electric appliance constitute the switch, the control staff can understand the machine working state at any time, and provide the guarantee for the scientific use of the machine;
Meshing gear shift, gear brake mechanism to ensure that the product is durable.
Also have 20-140hp four wheel tractot ,welcome contact with us.
SPECIFICATION:
Main parameters | CD40 Product series | |||||
Type | 354 | 404 | 454 | 504 | 554-1 | |
Drive type | four-wheel drive | four-wheel drive | four-wheel drive | four-wheel drive | four-wheel drive | |
Engine | ||||||
Engine Brand | laidong | Quanchai | ||||
Rating power of engine | 25.7/2350 | 29.4/2400 | 33.1/2400 | 36.8/2400 | 40.4/2400 | |
Fuel consumption @ nominal power | ≤258 | ≤248 | ≤248 | ≤248 | ≤248 | |
Displacement | 4/2.156 | 4/2.672 | 4/2.977 | 4/3.168 | 4/4.087 | |
Air filter type/size | Oil bath 6.5inch 180m3/h | Oil bath 7.8inch 255m3/h | ||||
Torque reserve | 19% | 23% | 18% | 20% | 27% | |
Transmission system | ||||||
Clutch type/size | One-piece,dry,double-action/10 inches | One-piece,dry,double-action/10 inches | One-piece,dry,double-action/10 inches | One-piece,dry,double-action/10 inches | One-piece,dry,double-action/10 inches | |
Max. speed | 30.49 | 34.78 | 34.78 | 34.78 | 34.78 | |
Hydraulic system | ||||||
Hydraulic output flow rate | 38.4 | 38.4 | 38.4 | 38.4 | 38.4 | |
Hydraulic filter types and capacity | wire mesh/63μm | wire mesh/63μm | wire mesh/63μm | wire mesh/63μm | wire mesh/63μm | |
Working device | ||||||
PTO Speed | 540/760rpm | 540/760rpm | 540/760rpm | 540/760rpm | 540/760rpm | |
kn Lifting Capacity | 9KN | 9KN/15KN(Enforced lift) | 9KN/15KN(Enforced lift) | 9KN/15KN(Enforced lift) | 9KN/15KN(Enforced lift) | |
Parameter | ||||||
Min. operation mass | With cab | 2200 | 2300 | 2300 | 2415 | 2640 |
Without cab | 2112 | 2120 | 2120 | 2135 | 2360 | |
Rated traction force(N) | 10.5 | 11 | 11.3 | 14 | 14.5 | |
Minimum ground clearance | 265 | 325 | 325 | 325 | 325 | |
tyre size | 7.50-16/11.2-28 | 8.3-20/12.4-28 | 8.3-20/12.4-28 | 8.3-20/12.4-28 | 8.3-20/12.4-28 | |
(options: all these types can Optional for ROPS ,Sunshade,swing drawbar, front/rear ballast,cabin) | ||||||
PACKAGE BY CONTAINER
FACTORY SHOW
Optional tools:
WHY CHOOSE US
1. Professional supply with certification: CCC, ISO,CE,DOT and so on
2. Perfect quality program. 100% test before delivery
3. One year guarantee.
4. OEM cervice.
5. Creative design team and first class quality equipments.
6. Design and Producing be customized.
7. Flexible payment. T/T L/C D/P,WESTERN UNION be accept.
BOTA BRAND walking tractor looking for sole agnt from every country and city.
