Thicker Sheet guillotine Shear Blade/Knife:
Steel-choosing→Blanking →Forging Steel →Rough Processing →Heat treatment →Finishing→Testing
Thicker Sheet guillotine Shear Blade/Knife Manufacturer are available with polished side faces ,High cost performance ,Punctual delivery .
Thicker Sheet guillotine Shear Blade/Knife are manufactured to a thickness tolerance of ±0.002mm-0.003mm(±0.00007 inch-±0.00012inch).
Parallelism tolerances is within 0.003mm (0.00012 inch) These are all prerequisites for the best possible slitting results.
Materials: 9CrSi ,6CrW2Si , H13 ,Cr12MoV ,G1 , G2 ,G3 and etc .
Steel-making by medium frequency furnace:
Huanxin company can meet special requirements for materials . In order to guarantee the quality ,the company imported the spectrometer from Germany and is equipped with various testers,such as tensile tester,impact testing machine,metallography analyzer and so on .
Electro slag remelting:
The largest ingot can reach 3 tons in Huanxin company .The ingot obtained by this remelting/refining process is very homogeneous and free of internal defects . The segregation of the ingot (called macro-segregations ) are substantially eliminated and the segregations of crystals (called macro-segregations ) are significantly reduced .
The ESR remelted material improve following mechanical characteristics :
---Improved toughness due to increased homogeneity and isotropy
---Improved creep resistance properties
----Best fatigue strength and tenacity properties as well as outstanding tensile strength
----Improved purity
Forging steel:
The largest electro-hydraulic hammer is 4.5 ton .And more than 6 skilled technicians work for us .After forging ,the inside microstructure becomes much closer and the metal grain size becomes much smaller . It can evevate the characteristics and quality of the knife ensuring a longer life .
Rough processing:
No less than 40sets of processing equipment in the rough processing workshop of Huanxin company , including lathe ,milling machine , planer , drill machine etc. Skilled workers are employed in its rough processing workshop .
Heat treatment:
Huanxin company has independent workshop for heat treatment . Couples of skilled technicians work here . Actually , most blades ( thickness ≤100mm) can be fully hardened . Thus ,the blades can be used after repairing until the size reached the minimum design dimension .
Finishing:
Huanxin company has more than 35 sets of processing equipment including internal grinder , external grinder , surface grinder ,CNC grinder ,electric spark CNC wire-cut etc. The company can produce the shearing blades with 5500mm in length and slitting knives with 1300mm in outside diameter .
Testing:
Various testers are put to use for testing its products in Huanxin machine company . They are including tensile tester , impact testing machine , metallography analyzer , harmless flaw detector , magnetic powder inspection , hardness tester , caliper rule , microcalliper , etc . Testing is carried out after each step . And every product has a unique track number . Thus it is easy to trace back anytime .
| MATERIALS FOR CHOICE | |||||||||||||
GB |
ASTM | JIS | DIN | W-Nr | NF | POCT | SS14 | BS | ISO | ||||
| 9CrSi | - | - | 90CrSi5 | 1.2108 | - | 9XC | 2090 | - | - | ||||
| 6CrW2Si | - | - | -60WCrV7 | 1.2550 | (-55WC20) | 6XB2C | - | - | -60WCrV2 | ||||
| Cr12MoV | - | SKD11 | X165CrMoV12 | 1.2601 | - | X12M | 2310 | - | - | ||||
| Cr12Mo1V1 | D2 | - | X155CrVMo12-1 | 1.2379 | X160CrMov12 | - | - | BD2 | 160CrMoV12 | ||||
| 4Cr5MoSiV1 | H13 | SKD61 | X40CrMoV5-1 | 1.2344 | X40CrMoV5 | 4X5M ∅ 1C | - | BH13 | 40CrMoV5 | ||||
| LD | - | - | - | - | - | - | - | - | - | ||||
| W18Cr4V | T1 | SKH2 | S 18-0-1 | 1.3355 | HS 18-0-1 | P18 | 2750 | BT1 | HS 18-0-1 | ||||
| W6Mo5Cr4V2 | M2 | SKH9 | S 6-5-2 | 1.3343 | - | P6M5 | 2722 | BM2 | HS 6-5-2 | ||||
| 45 | 1450 | S45C | C45E | 1.1191 | C45E | 45 | 1660 | C40E | C45EC | ||||
| 42CrMo | 4140 | SCM440 | 42CrMo4 | 1.7225 | 42CD4 | - | 2244 | 708M40 | 42CrMo4 | ||||
| T8 | W1A-8 | SK5 | C80W2 | 1.1625 | (C80E2U) | Y6 | 1778 | - | TC80 | ||||
Payment Terms:
♦ 30%−50% down payment in advance and the balance before shipment.
♦ Paypal,Westen Union,T/T, Unionpay ,Excrow Service,Visa,LC,etc.
Samples Offering:
♦ Samples is available.
♦ Freight collect.
Delivery Time:
♦ 5-10 Days For Few Quantity.
15-25 Days For Large Quantity.
♦ Personalized Customization Is Acceptable.
Transportation:
*5-10 Days by Express.(UPS,DHL,TNT,FedEX,EMS,etc.)
*2-3 days by Air (EXW,FOB,FCA,CIF,CPT,DAF,DDP etc.)
*25-45 days by Sea (EXW,FOB,FCA,CIF,CPT,DAF,DDP etc.)
Material and hardness are much important to the work life for blades, according to over 10 years experience, Xiamen Huanxin will provide you professional advice and recommend you best material and hardness according to the applications of blades with competitive price.
We can custom made blades according to your drawing or description. In order to provide prompt and accurate quotation, it's better that you can provide us the quantity, drawings, cutting application and etc of blades.
All of your inquiry and emails will be replied within 24 hours. We believe No excuse for failure, only the action for success. You are welcome to visit our factory.
1, What is your capacity?
Both our heat treatment facility and grinding machines allow for straight knives up to 7 meters (or 275 inches) long, no segment
at all, in a single piece, while for circular knives up to 1500mm in O.D.
2, How do you guarantee your quality?
Material selection and hardness survey are critical for blade quality. We were formally engaged in forging, and had a good command of mechanics and property of different tool steels. Inspection on incoming materials is furthermore well taken care of. Long-term raw providers physically near to us, that help make us more competitive, ensured quality. We are serious and all our blades parts are always forged while those parts from most of our competitors are not.
3, What's price?
Always we will quote you price based on drawings, or you can tell us the dimension. Then according to your application and quantity, we will send you quotation in time. The price is differ from different materials .
4, What's the material and hardness?
According to your application, we will recommend you the best material and hardness.
Optional Materials :9CrSi, 6CrW2Si , LD , D2 , Cr12MoV , H13 , G1, G2 ,G3 and etc.
5, Do you handle shipments?
Definitely yes. Usually in a quotation sheet, an Ex factory price is offered. We are, however, happy to offer FOB POL (Port of Loading) or CIF POD (Port of Destination) as requested. As a manufacturer, we have more shipments to handle than you do, and this advantage enables us to get better rates, which in turn we get back to you. Besides, we have better connections to handle custom inspection and unexpected conditions.
Xiamen Huanxin Machine is a manufacturer of standard and precision circular and rectangular replacement industrial machine cutting blades for all levels of the paper, paperboard and corrugated industries over ten years. Huanxin provides machine knives to manufacturers and converters of plastics, laminates, flexible materials, films, foils, thin metals, non-woven materials, textile, tire and rubber materials to circuit boards, synthetic components, roofing materials, and more.
Our products are applicable to industries and machines such as Metallurgical industry, Food processing industry, Chemical industry, Textile industry, Wood processing industry, Paper making industry, Pipe manufacturing industry, Printing and packaging industry, Plastic and Rubber processing industry, Paper and Foil cutting machines, Metal and Non-metal slitters and Precision slitting machines.
Based on rich manufacturing experience and strong technology, strict management and quality inspection systems, quality and delivery time are ensured. For every one of the product to be made, Huanxin will take the most responsible attitude in this field to fit customer's specific applications to maximize production requirements.
