Product Details
Place of Origin: | Fujian, China | Brand Name: | Huanxin | Model Number: | K-98 |
Type: | Saw Blade | Blade Material: | Tungsten Carbide Steel | Finishing: | White |
Size: | Customer |
Product Description
SPLIT BAND BOTTOM SLITTER ANVILS Split bottom slitter band
Specification:(customized shape and dimension is acceptable!)
Split bottom slitter bands are a time-saving product used in shear slitting operations when the change out speed for the bottom slitter anvil is critical.
Split bottom slitter band are precision manufactured with exceptional standards of quality for true running, high-speed operation. All the slitter blades ; are held to close tolerance accuracies for concentricity and dimensional integrity.
SPLIT BAND BOTTOM SLITTER ANVILS can be supplied for all types of metric equipment, made to unmatched reliable performance and operating efficiencies.
Manufactured in-house to precise specifications, Valley Grinding Rotary/Circular Top Slitter Blades / Knives provide a perfect fit, extremely dependable performance and a variety of design options including:
♦ Use of D-2 and/or tungsten carbide eliminates frequent regrinding, saving you time and protecting your knife investment.
♦ Through-hardened to enhance wear resistance and toughness.
♦ Precision machined, finish ground and super finished to provide minimum lateral runout and excellent concentricity, while enhancing the performance of the top shear slitter blade used against the bands.
♦ Super finish and edge sharpness minimizes dust production and improves cut quality.
♦ Available for any machine where the bottom slitter anvil is shaft mounted.
You simply use an Allen wrench to quickly take the split bottom slitter anvil off the machine shaft and replace it with a sharp anvil. Then you bolt the worn slitter anvil halves together and send them back to Kinetic for sharpening.
Upgrading to split band bottom slitter bands in your operation results in a very fast ROI due the dramatic drop in machine downtime. Instead of having to pull the shaft and slide the anvils off – often talking hours – you unbolt the dull anvils and replace them in minutes.
MATERIALS FOR CHOICE | |||||||||||||
GB | ASTM | JIS | DIN | W-Nr | NF | POCT | SS14 | BS | ISO | ||||
9CrSi | - | - | 90CrSi5 | 1.2108 | - | 9XC | 2090 | - | - | ||||
6CrW2Si | - | - | -60WCrV7 | 1.2550 | (-55WC20) | 6XB2C | - | - | -60WCrV2 | ||||
Cr12MoV | - | SKD11 | X165CrMoV12 | 1.2601 | - | X12M | 2310 | - | - | ||||
Cr12Mo1V1 | D2 | - | X155CrVMo12-1 | 1.2379 | X160CrMov12 | - | - | BD2 | 160CrMoV12 | ||||
4Cr5MoSiV1 | H13 | SKD61 | X40CrMoV5-1 | 1.2344 | X40CrMoV5 | 4X5M ∅ 1C | - | BH13 | 40CrMoV5 | ||||
LD | - | - | - | - | - | - | - | - | - | ||||
W18Cr4V | T1 | SKH2 | S 18-0-1 | 1.3355 | HS 18-0-1 | P18 | 2750 | BT1 | HS 18-0-1 | ||||
W6Mo5Cr4V2 | M2 | SKH9 | S 6-5-2 | 1.3343 | - | P6M5 | 2722 | BM2 | HS 6-5-2 | ||||
45 | 1450 | S45C | C45E | 1.1191 | C45E | 45 | 1660 | C40E | C45EC | ||||
42CrMo | 4140 | SCM440 | 42CrMo4 | 1.7225 | 42CD4 | - | 2244 | 708M40 | 42CrMo4 | ||||
T8 | W1A-8 | SK5 | C80W2 | 1.1625 | (C80E2U) | Y6 | 1778 | - | TC80 |
Specification | Out diameter(mm) | Inner diameter(mm) | Thickness(mm) |
∅200×∅122×1.3 | 200 | 122 | 1.3 |
∅210×∅122×1.3 | 210 | 122 | 1.3 |
∅230×∅110×1.3 | 230 | 110 | 1.3 |
∅230×∅130×1.3 | 230 | 130 | 1.3 |
∅240×∅32×1.2 | 240 | 32 | 1.2 |
∅240×∅32×1.2 | 240 | 32 | 1.2 |
∅250×∅105×1.35 | 250 | 105 | 1.35 |
∅250×∅130×1.35 | 250 | 130 | 1.35 |
∅260×∅112×1.4 | 260 | 112 | 1.4 |
∅260×∅114×1.35 | 260 | 114 | 1.35 |
∅260×∅158×1.35(hole) | 260 | 158 | 1.35 |
∅260×∅158×1.35(non-hole) | 260 | 158 | 1.35 |
∅260×∅168.3×1.5 | 260 | 168.3 | 1.5 |
∅270×∅168.3×1.5 | 270 | 168.3 | 1.5 |
∅280×∅168×1.4 | 280 | 168 | 1.4 |
∅280×∅202×1.4 | 280 | 202 | 1.4 |
∅300×∅112×1.35 | 300 | 112 | 1.35 |
: | : | : | : |
∅610×∅68.3×4.7 | 610 | 68.3 | 4.7 |
Payment Terms:
♦ 30%−50% down payment in advance and the balance before shipment.
♦ Paypal,Westen Union,T/T, Unionpay ,Excrow Service,Visa,LC,etc.
Samples Offering:
♦ Samples is available.
♦ Freight collect.
Delivery Time:
♦ 5-10 Days For Few Quantity.
15-25 Days For Large Quantity.
♦ Personalized Customization Is Acceptable.
Transportation:
*5-10 Days by Express.(UPS,DHL,TNT,FedEX,EMS,etc.)
*2-3 days by Air (EXW,FOB,FCA,CIF,CPT,DAF,DDP etc.)
*25-45 days by Sea (EXW,FOB,FCA,CIF,CPT,DAF,DDP etc.)
Material and hardness are much important to the work life for blades, according to over 10 years experience, Xiamen Huanxin will provide you professional advice and recommend you best material and hardness according to the applications of blades with competitive price.
We can custom made blades according to your drawing or description. In order to provide prompt and accurate quotation, it's better that you can provide us the quantity, drawings, cutting application and etc of blades.
All of your inquiry and emails will be replied within 24 hours. We believe No excuse for failure, only the action for success. You are welcome to visit our factory.
FAQ
1, What is your capacity?
Both our heat treatment facility and grinding machines allow for straight knives up to 7 meters (or 275 inches) long, no segment
at all, in a single piece, while for circular knives up to 1500mm in O.D.
2, How do you guarantee your quality?
Material selection and hardness survey are critical for blade quality. We were formally engaged in forging, and had a good command of mechanics and property of different tool steels. Inspection on incoming materials is furthermore well taken care of. Long-term raw providers physically near to us, that help make us more competitive, ensured quality. We are serious and all our blades parts are always forged while those parts from most of our competitors are not.
3, Do you handle shipments?
Definitely yes. Usually in a quotation sheet, an Ex factory price is offered. We are, however, happy to offer FOB POL (Port of Loading) or CIF POD (Port of Destination) as requested. As a manufacturer, we have more shipments to handle than you do, and this advantage enables us to get better rates, which in turn we get back to you. Besides, we have better connections to handle custom inspection and unexpected conditions.
Xiamen Huanxin Machine is a manufacturer of standard and precision circular and rectangular replacement industrial machine cutting blades for all levels of the paper, paperboard and corrugated industries over ten years. Huanxin provides machine knives to manufacturers and converters of plastics, laminates, flexible materials, films, foils, thin metals, non-woven materials, textile, tire and rubber materials to circuit boards, synthetic components, roofing materials, and more.
Based on rich manufacturing experience and strong technology, strict management and quality inspection systems, quality and delivery time are ensured. For every one of the product to be made, Huanxin will take the most responsible attitude in this field to fit customer's specific applications to maximize production requirements.
If you are interested in any Circular Knife please send us an inquiry about that knife and we will try to supply it for you in a short term at the best price.
