Massey Ferguson Tractor MF 385 (2WD 85HP) Millat Pakistan

Specifications

Sole & Authorized Distributor of Massey Ferguson & Millat Tractors, Manufacturer Exporter Best Quality Agricultural Implements

We are the Sole distributor and Exporter of Massey Ferguson Tractor in the World wide.
Massey Ferguson is the top Brand Name in world of Tractor Machinery.
We have different Design and Types.
We have the Best and A+Grade Quality Tractors & also their Empliments

•  High Performance 4.41, low noise Engine
• Gaseous Emmissions under ECE R49
• Reduced Smoke Level
• Oil Cooler added for effective cooling
• Hydrostatic Power Steering
• Efficient Oil Immersed Disc Brake System
• Spring Suspension Deluxe Seat
• Easy Accessibility to Service points





PERFORMANCE:
Rated Engine Power at 2,200 rpm: *85 HP Max. Engine Torque at 1,600 engine rpm: 291 Nm Max. P.T.O. power at 2,200 engine rpm: *70 HP * Manufacturer's Estimate
ENGINE:
Rated Engine Power at 2,200 rpm: *85 HP Max. Engine Torque at 1,600 engine rpm: 291 Nm Max. P.T.O. power at 2,200 engine rpm: *70 HP * Manufacturer's Estimate
ELECTRICS:
Voltage: 12 Volt, Negative Earth Battery : 96 Ah Starter Motor : 2.8 kW Alternator : 45 A Light: Head Lights, Side Lights, Brake Light, Direction Indicators, Rear Work Lamp Safety Start: Transmission & PTO Other: Horn
CLUTCH:
Type: Dual Diameter: 305 x 254 mm (12 in x 10 in)
POWER TAKE - OFF:
Type: Live Engine Speed at 540 PTO rpm: 1,789 rpm Shaft Diameter: 35 mm (1.38 in) No. of Splines: 6
TRANSMISSION:
Type: Sliding Spur No. of Gears: 8 Forward, 2 Reverse Road Speed @ rated engine speed with 18.4/15 - 30 rear tyres: Gear       Speed mile/h (km/h)   Forward  Forward Forward Forward Forward Forward Forward Forward Reverse Reverse   1 1.7 (2.25) 2 2.3 (3.7) 3 3.2 (5.1) 4 4.2 (6.8) 5 6.4 (10.4) 6 9.4 (15.2) 7 12.9 (20.8) 8 17.3 (27.9) 1 2.1 (3.5) 2 8.8 (14.1)
HYDRAULICS:
Functions: Draft, Piston, and Response Control Constant Pumping Pump Type: Four-Piston, Ferguson Pump Max. Oil Flow: 16.7 liter/min (3.67 imp. gal/min), 207 bar (3000 lbf/in2) (At nominal Operating Temperature) Max. Pressure: 207 bar (3,000 psi) at normal operating temperature Max. Lift Capacity at Lower Links horizontal: 2,145 Kg (4,728 lb) Lower Links: Cat 1 & 2 with Interchangeable Balls.
WEIGHTS AND DIMENSIONS:
Weight Front Axle: 1,228 Kg (2,701 lb.) Weight Rear Axle: 1570 Kg (3,461 lb.) Total:  2,798 Kg (6,162 lb.) DIMENSION: Wheel Base: 2,286 mm (90 in) Overall Length: 3,760 mm (148 in) Width (Min.):  1,871 mm (73.7 in) HEIGHT: Over Exhaust:  2,485 mm (97.8 in) Over Steering Wheel: 1,781 mm (70.1 in) TURNING CIRCLE: Without Braking: 7,502 mm (295 in) GROUND CLEARANCE: Under Gear Box: 501 mm (19.8 in)
CAPACITIES:
Fuel Tank:  108 liter (23.8 lmp. gal) Engine Sump: 7.5 liter (13.2 lmp. pint) Air Cleaner: 0.7 liter Cooling System: 15.2 liter (26.8 lmp.pt) Hydraulic System:  36 liter Hydrostatic Steering Reservoir: 2 liter
STANDARD EQUIPMENT:
Chain Stabilizers, Check Chains, Spring-suspension Seat, Flat Top Fenders, Standard Tool Box with set of Tools, Weight Frame without weights, Top Link, Cat-2 balls, Operator's manual
OPTIONAL EQUIPMENT:
- Front End Weights - PTO Pulley - Sun Canopy - 9 Hole Draw Bar
