Help CenterChina ISO High Quality Steel Landing Gear Sale
Related Products
-
China ISO High Quality Steel Holland Landing Gear for SaleUS$ 120 - 160MOQ: 10 Pairs -
China Steel High Quality ISO Lifting Landing GearUS$ 120 - 160MOQ: 10 Pairs
-
China ISO High Quality Steel T Type Landing GearUS$ 120 - 160MOQ: 10 Pairs
-
China ISO High Quality Steel Outside Landing GearUS$ 120 - 160MOQ: 10 Pairs
-
China Heavy Duty Best Quality Steel ISO Landing GearUS$ 120 - 160MOQ: 10 Pairs
Landing Gear Sale Information:
> Type: Fuwa type
> Dimention of LGH28-A0101T:
> Capacity: 28T Landing Gear
> Static Load: 80T
> Plate Thickness:5 mm
> Speed: Higher 3.5mm, Lower 0.42mm
> Lift/Height: 430/794mm; 480/844mm
> Length: Gear Bar Length can be Adjusted
Wondee Autoparts Landing Gear Factory supplies landing foot for semi-trailers & RV semi-trailers.
Gear Box: Inside & Outside
Operation: Single side & Double side
Lifting Capacity: 25 ton ~ 35 ton.
Static Load: 50 ton ~ 90ton
Gear Foot Type: T, A, S, G, R
Out put: 80,000 pairs yearly
Steel Landing Gear Sale Dimension :
Number |
Capacity |
Static Load |
Speed |
Lift |
Height |
|
kg |
kg |
Higher |
Lower |
mm |
mm |
|
LGH28-A0101T |
28000 |
80000 |
3.5 |
0.42 |
430 |
794 |
LGH28-A0102T |
28000 |
80000 |
3.5 |
0.42 |
480 |
844 |
The Detail photos about Landing Gear Sale :
High Quality Steel Landing Gear Sale Drawings ( Just for Reference ) :
Landing Gear Sale Specifications ( Just for Reference ):
- Reliable, high-quality seal keeps water out and extends life
- Unique tapered backplate for enhanced durability
- Gearbox with low-temperature premium lube provides easy cranking and reduces component wear; protection from -65ºF to 225ºF
- Low Speed Gear - 38.6 turns per inch
- High Speed Gear - 4.5 turns per inch
- Massive, 5-inch upper housing with 80,000 psi minimum yield and retractable tube; maintains strength while saving weight. Lower leg is 12% larger than standard-duty landing gear
- Three-gear train gearbox with exclusive Man-Saver gear ratios handles normal loads with 40% less effort
- Exceeds all AAR M-931 and all TTMA RP-4 performance specifications.
- Includes an industry leading 5-year warranty
Landing Gear Sale Function & Attention ( Just for Reference ) :
1.The device is use for semi-trailer and special trailers.
2.It lift and support trailer when it is separated from tractor.
3.It's also in use for all sorts of trucks that they are secured to work as jack.
4.The quality is up to the standard of American ABS specification.
5.Landing Gear has slow and fast two speed. Please use slow speed when loading. It is easy to operate. Do not use fast speed. It is possible to injure landing gear.
Besides Landing Gear Sale, WONDEE AUTOPARTS also Supply SEMI TRAILER, WHEEL RIM,LANDING GEAR,SUSPENSION ... .... ...
