Home > Products > Trailer & Semi-trailer (CKD) > Tri-Axle 40000 Liters Fuel Oil diesel Tank Semi Trailer Fuel Truck Semitrailer
Tri-Axle 40000 Liters Fuel Oil diesel Tank Semi Trailer Fuel Truck Semitrailer
- 200 Set / Sets per Month
- Fujian Qingdao Shaihai
- T/T Credit Card
- Trailer Manufacturing 3 Axles 40000liters Stainless Steel Tank Trailers for Sale
- 3 Axles Stainless Steel Fuel Semi Trailer Tanker for Sale
- Stainless Steel 3 Axles Oil Tanker Semi Trailer
- 3 Axle Fuel Tanker Stainless Steel Tank Trailer
- Stainless Steel 3 Axle Fuel Tanker Semi Trailer
- 3 Axle Aluminum Alloy Fuel Tanker Trailer for Sale
Product Details
Type: | Semi-Trailer | Material: | Other, Fuel Oil diesel Tank Semi Trailer | Certification: | Other, ISO/TS16949 |
Size: | 12m*2.5m*3.8m | OEM No.: | Fuel Oil diesel Tank Semi Trailer | Max Payload: | 42T |
Place of Origin: | Fujian, China | Brand Name: | WONDEE | Model Number: | Fuel Oil diesel Tank Semi Trailer |
Packaging Details
Tri-Axle 40000 Liters Fuel Oil diesel Tank Semi Trailer Fuel Truck Semitrailer package:2 Units in 2x40'HQ and 1*20'GP, CBU or CKD or SKD
Product Description
Transportation purpose and characteristic
Fuel tanker semi trailer is a special vehicle widely used in transportation of crude oil, petrol,diesel,etc.
The vehicle has reasonable structure, flexible steering, wonderful insulation effeat, reliable braking system.It is easy to use and maintain.
Tri-Axles 40000Liters Fuel Oildiesel Tank Semi Trailer Fuel Truck Semitrailer Dimension:
OVERALL DIMENSION:12m*2.5m*3.8m | ||||
TANKER VOLUME:40m3 | ||||
CURB WEIGHT:9.8 Ton | ||||
PAYLOAD:42 Ton | ||||
CHASSIS | UNIT | QTY | REMARKS | |
1 | Main Beam | SET | 1 | SUS304 |
2 | Support beam | SET | 1 | SUS304 |
3 | Painting | SET | 1 | Impeller blasting ; Colour according to the customer request |
TANKER DETAIL | ||||
1 | Tanker body | SET | 1 | SUS304 Thickness:5mm |
2 | End plate | SET | 2 | SUS304 Thickness:6mm |
3 | Compartment | PC | 1 |
|
4 | Corrugated shape - Wash plate | PC | 7 | SUS304 Thickness:4mm |
5 | Ladder | PC | 2 | In the rear and front , Bolted |
6 | Overturn protection | PC | 2 | Full length valance,with tripod and ties in the end |
7 | Tank walkways | SET | 1 | Welded tread pattern strips |
OPERATION SYSTEM | ||||
1 | SUS304 Manhole | PC | 2 | Made in China |
2 | SUS304 Pneumatic bottom valve , 4-inch | PC | 1 | Made in China |
3 | SUS304 Rack unloading valve , 3-inch | PC | 2 | Made in China |
RUNNING SYSTEM | ||||
1 | Axles | PC | 3 | 13 TON American Type Axles |
2 | Suspension system | SET | 1 | Leaf-spring suspension, |
3 | Wheel rim | PC | 12 | 9.0*22.5 |
4 | Tyre | PC | 12 | 12R22.5 |
5 | Kingpin | PC | 1 |
|
6 | Landing legs | SET | 1 | 28ton Two-speed linkage |
PNEUMATIC BRAKE SYSTEM | ||||
1 | Spring brake chamber | PC | 6 |
|
2 | Air connector | SET | 1 |
|
3 | Valve | PC | 1 |
|
4 | ABS system | SET | 1 | BRAND:KEMI, |
ELECTRONICAL SYSTEM | ||||
1 | 7-Pin Socket | SET | 1 | One unit of 24V 7-pin socket |
2 | LED Lamp | SET | 1 | Full set of LED lamp |
3 | Cable | SET | 1 | One set of stander cable |
ACCESSORIES | ||||
1 | Tool box | PC | 1 |
|
2 | Wheel carrier | SET | 1 |
|
3 | Fire extinguisher | PC | 2 |
|
4 | Unloading hose | PC | 2 |
|
5 | Plastic fender | PC | 6 |
Tri-Axle 40000 Liters Fuel Oil diesel Tank Semi Trailer Fuel Semitrailer Detail Photos:
Factory Corner
More models of semi-trailer for your optional:
Company Profile
Xiamen Wondee Autoparts Co., Ltd (CHINA), has been supplying a wide variety of semi-trailers, trucks and trailer components including leaf spring, wheel rim, air suspension, spring steel flat bar, axle, suspension, bogie, landing gear, turntable, fifth wheel, king pin, air chamber, slack adjuster, twist lock and so on.
Our TOP 5 most attractive export products are:
1. SEMI-TRAILER
Popular trailers include skeletal container semi-trailers, flatbed semi-trailers, fuel tank semi-trailers, low bed semi-trailers, van semi-trailers, logging semi-trailers. We supply complete and partial CKD package for semi-trailers also.
2. LEAF SPRING
We are the largest leaf spring manufacturer group in Asia with an annual output 200,000 tons, have passed ISO/TS16949 certificate in 2006. We engage in the production of all kinds of automobile spring, from small trailers, pickup vehicles to heavy duty trucks, from conventional to parabolic, from OEM to after-market. Thickness from 6mm to 50mm, width from 44.5mm to 125mm. Popular material grades include SUP7, SUP9 and SUP11A. Popular section sizes include 44.5*6, 50*8, 57*8, 60*12, 70*9, 80*13, 90*16, 100*12, 100*38, 100*50, 120*20.
3. WHEEL RIM
Tube wheel from 5.5-16 to 8.5-24; tubeless wheel rim from 6.0*17.5 to 11.75 * 22.5 for all kinds of vehicles. Popular size is 7.5-20, 8.5-24, 9.00*22.5, 11.75*22.5.
4. SPRING STEEL FLAT BAR
Popular material grades include SUP7, SUP9 and SUP11A. Popular section sizes include 44.5*6, 50*8, 57*8, 60*12, 70*9, 80*13, 90*16, 100*12, 100*38, 100*50, 120*20.
5. AIR SUSPENSION
Popular type is 3-axle liftable air suspension for semi-trailer.
With the experienced R&D staff, advanced production equipments, strict quality control system, our factories have passed ISO/TS16949 international standards and have been approved by Xiamen Municipal Trade Development Bureau to be in the range of "Private Scientific & Technological Enterprise". Meanwhile, reasonable price, qualified goods, PPAC order service, all these advantages make WONDEE famous and prestigious all over the world.
WONDEE have acquired high reputations from our customers both in local automobile industry and in oversea markets. During the past years, WONDEE products are well sold to Malaysia Port Kelang, Thailand Bangkok, Saudi Dammam, Nigeria Lagos, Tanzania Darlassalam, Brazil Santos, USA Texas, Germany Hamburg and so on. It has been found that, WONDEE products are especially suitable for bad roads and over-load conditions transportation, for example, in the ore mining area of Africa, in the mountain areas of Latin America, in the oil-output region of Mideast, in the coal mining areas in China Fujian.
To maximize customer satisfaction, WONDEE put not only great attention to the superior product quality and good cost performance, but also has been building up a complete and satisfied service principle, called as "PPAC": Prompt---Pre-act---Accurate---Considerate.
Presently, the people of WONDEE offer our warm welcome to the clients at home and abroad to visit our factory in coming future for the greater cooperation based on long-term "win-win" development.
Sincerely
Yours
Ms Amy Ai
Contact Us
- Xiamen Wondee Autoparts Co., Ltd.
- Contact nameRichard Luo
- Phone86-592-5618109
- AddressF.5, No.7 building,Xinhe industrial park,Dianqian, Huli,Xiamen, China 36100 Xiamen,Fujian
