3 Axle LPG Tank Semi-trailer Information:
Standard in China | |
Pressure vessels | |
GB/T19905-2005 Liquefied gas truck | |
Movable Pressure vessel safety technology and inspection procedures | |
Tanker Essential Information | |
Dimensions(length*width*height) |
11500*2500*3750(mm) |
Estimated Tare Weight |
14500KG |
Payload |
18900KG |
Total Weight |
33400KG |
Shell Of Tanker | |
Products |
LPG , Propane |
Fluid property |
Flammable |
Design temperature |
to 50℃ |
Design pressure |
1.61MPa |
Corrosion allowance |
2.0mm |
Major materials of bearing pressure |
Tanker body : Q345R , 12mm GB713 |
End plate : Q345R , 14mm GB713 | |
Main Beam : AG700(Non-bearing pressure material) | |
Filling weight per volume |
|
Maximum filling weight |
|
Compartments |
ONE |
Shape |
Round(elliptical) |
Detection | |
Heat treatment |
Overall heat treatment in a furnace , 600℃ to 640℃ |
Flaw detection |
100% Flaw detection |
Test PRESSURE |
1.61MPa |
Hydraulic test |
2.1MPa |
Magnaflux |
Aim at welding place flaw detection can not cover |
TERMS | |
Payment terms: |
30%TT in advance, balance before shipping |
Terms of delivery: |
In 30 days after received 30% advance payment |
Port: |
CHINA |
MOQ: |
1 unit |
3 Axle LPG Tank Semi-trailer Packing Photos:
More Semi Trailers As Bellow for you Reference:
Besides 3 Axle LPG Tank Semi-trailer, WONDEE AUTOPARTS also Supply LEAF SPRING, WHEEL RIM,LANDING GEAR,SUSPENSION ... .... ...
