RISTRON RSP02-C double channels&double push-pull digital lab industrial injection pump

Specifications

RISTRON RSP02-c double channels&double push-pull digital lab industrial injection pump

Function Introduction:

1.RSP series injection pump is widely used in chemical reaction injection experiments, long time animal drug injection experiments and other micro-injection experiments in laboratories.

2.3.5 inch (320 *240) LCD touch screen device & WinCE system built-in, the operation is simple and intuitive.

3.Can be connected to the wireless mouse remote control settings, making RSP injection pump work in enclosed environmentlike a ultra-clean table.

4.Connected with a pedal board device, to replace the frequent click operation, easily complete the experiment.

5.Injector internal-input function,you can chose a injector from the list or inpute the injector internal diameter.

6.Memory function for power failure:1)EEPROM can save setting parameters, needless reset again when power is on.2)If it’s out of power when it’s working on the flow mode of, it can keep working according to the parameter set before when power is on again.

7.Occlusion protection function: when the pushing mechanism of the injection pump is blocked in the working, the injection pump will stop pushing and give a warning.

8.485 bus communication is adopted and can be connected with a PC,control through the software.

external control interface: with input & output control functions.

9.Flow calibration function: a more accurate flow is got through the flow calibration procedure.

10.The injector protection:the position of the limiting block can be adjusted to revent the injector is impaired.

Specifications:

About US:

Jiashan Ruichuang Electronics Technology Company Limited is located in the central area of the Yangtze River Delta ( Jiashan National High-tech Industrial Park) in the high-tech innovation-oriented enterprises, mainly dedicated to the research & application of new digital automation technology. Now we have a research & development team made up by 16 members led by 2 doctoral & 5 masters.We have strong abilities on innovation of science and technology, and have won 9 national patents, 2 software copyrights.A number of technology is originated domestically.

Main Products:

E.CON Intelligent Industrial Control Module series: also known as E.CON program logic controller, (referred to as EPLC). to improve the efficiency of your product development.

E.CON Solutions: to provide you with the most stable, the most quickly, the most high-end solutons on control system.

Laboratory Equipment Based on the E.CON Core : digital injection pump, multifunctional liquid operation instrument, digital dilution device, electric pipette gun and other high-tech products.

In line with "Quality for Credibility, Innovation for Development", we're devoted to the upgrading,research & development of our products,to provid customers with perfect service.
