Help CenterStainless Steel 45 Degree Elbow
Related Products
Specifications
45 degree tread elbowStainless steel 45 degree elbow
with high quality and reasonable price!
Stainless steel 45 degree elbow
Sample and small order are accepted!
If you are interested into our product, freely send us drawing or sample. We can also design your wanted product according to your requirement.
Welcome your inquiry!
Threaded Fittings 1GB/T 14626,ASME B16.11
Normal pipe seze |
DN |
6,8,10 |
15,20,25 |
32,40,50 |
65,80,100 |
|
NPS |
1/8,1/4,3/8 |
1/2,3/4,1 |
11/4,11/2,2 |
21/2,6,4 |
||
|
90 Degre-e elbow Tee Cross
|
Center to end |
SCH80 2000 |
21,21,25 |
28,33,38 |
44,51,60 |
76,86,106 |
|
SCH160 3000 |
21,25,28 |
33,38,44 |
51,60,64 |
63,95,114 |
||
|
XXS 6000 |
25,28,33 |
38,44,51 |
60,64,83 |
95,106,114 |
||
|
45 Degre-e elbow |
Center to end |
SCH80 2000 |
17,17,19 |
22,25,28 |
33,35,43 |
52,64,79 |
|
SCH160 3000 |
17,19,22 |
25,28,33 |
35,43,44 |
52,54,79 |
||
|
XXS 6000 |
19,22,25 |
28,33,35 |
43,44,52 |
64,79,79 |
||
|
All fitting |
Outside diameter of band (D) |
SCH80 3000 |
22,22,25 |
33,38,46 |
56,62,75 |
92,109,146 |
|
SCH180 6000 |
22,25,33 |
35,46,56 |
62,75,84 |
102,121,152 |
||
|
XXS 9000 |
25,33,38 |
46,56,62 |
75,84,102 |
121,146,152 |
||
|
mnimum wall Thicknes-s |
SCH80 3000 |
3.18,3.18,3.18 |
3.18,3.18,3.68 |
3.89,4.01,4.27 |
5.61,6.99,6.55 |
|
|
SCH180 6000 |
3.18,3.30,3.51 |
4.09,4.32,4.98 |
5.28,5.56,7.14 |
7.65,8.54,11.18 |
||
|
XXS 9000 |
6.35,6.6,6.96 |
8.15,8.53,9.93 |
10.59,11.07,12.09 |
15.29,16.64,18.67 |
||
Lenth of thread min |
B |
6.4,8.1,9.1 |
10.9,12.7,14.7 |
17,17.8,19.0 |
23.6,25.9,27.7 |
|
L2 |
6.7,10.2,10.4 |
13.6,13.9,17.3 |
18,18.4,19.2 |
28.9,30.5,33 |
||
