3105 Aluminum Sheet-the Best 3105 Aluminum Sheet Manufacture in China

3105 Aluminum Sheet-the Best 3105 Aluminum Sheet Manufacture in China thumbnail-1
3105 Aluminum Sheet-the Best 3105 Aluminum Sheet Manufacture in China photo-1
US$ 2000 - 4500 MOQ: 5 Tonnes
Key Specifications
Get Latest Price
Brand Name:
Huawei
Place of Origin:
China
Model Number:
3105
Contact Supplier Request Quote Chat Now
Henan Huawei Aluminum Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Huawei
Place of Origin China
Model Number 3105
Type Plate
Alloy Or Not Is Alloy
Grade 3000 Series
Temper O-H112
Properties of 3105 Aluminum Sheet

3105 aluminum sheet/coil with 98% pure aluminum and slight alloy additions for strength. 0.3% of copper is added to 3105 aluminum sheet/coil, so the conductivity turns out to be 41%. For its contents and processing technologies, 3105 aluminum sheet/coil is light in weight and it has semi-smooth surface. Besides, it is not hardened by heat treatment. All the products Of Henan Huawei Aluminum Co., Ltd live up to international standards, such as ASTM, EN, JIS, etc. Therefore, quality of 3105 aluminum sheet/coil can also be guaranteed. Henan Huawei Aluminum Co., Ltd. can supply particular specifications at customers` need besides the following.

Elements Si Fe Cu Mn Mg Cr Zn Ti Others Al
Content 0.6 0.7 0.3 0.3-0.8 0.2-0.8 0.2 0.4 0.1 0.15 Remain
Alloy
Temper

Specified

thickness

Tensile
strength 		Yield
strength 		Elongation
(inches) (KSI) (KSI) (%)

3105-O

(annealed)

0.013-0.019 96-145 Min34 16
0.020-0.031 18
0.032-0.080 20
3105-H12 0.017-0.019 131-179 Min103 1
0.020-0.031 1
0.032-0.050 2
0.051-0.080 3
3105-H14 0.013-0.019 152-200 Min124 1
0.020-0.031 1
0.032-0.050 2
0.051-0.080 2
3105-H16 0.013-0.031 172-221 Min145 1
0.032-0.050 2
0.051-0.080 2
3105-H18 0.013-0.031 Min193 Min165 1
0.032-0.050 1
0.051-0.080 2
3105-H25 0.013-0.019 Min15 Min131 2
0.020-0.031 3
0.032-0.050 4
0.051-0.080 6
  Features and Applications of 3105 Aluminum Sheet

Mg, Mn and Si are added to 3105 aluminum sheet, thus, it has excellent correction resistance, formability and welding characteristics. Besides, it has average mechinability and it can be increased in harder tempers than in annealed condition. Oil lubricants should be used for all machining operations. The forming characteristics of 3105 aluminum sheet/coil are pretty good by all conventional processes regardless of temper. But 3105 aluminum sheet/coil does not respond to heat treatment except for annealing during cold working. The cold working characteristics are very good, even in the harder cold working tempers. For all the features above, 3105 aluminum sheet/coil has a vast application in many field.


Pay attention to Henan huawei alumium CO., LTD for more information about 3105 Aluminum Sheet：/3000-Aluminum-Sheet.html

Product Tags: 3105 Aluminum Sheet , Aluminum Sheet , Aluminum Sheet manufacture
