360 Degree Electronic Drawing Protractor

About Product

360 degree electronic drawing protractor

The Digital Protractor is a revolutionary measuring tool to build 0.1° accuracy at vertical and horizontal planes and 0.2° accuracy at other angles.

The stainless steel frame with integral base-plate is light, rigid and ultra-precise platform

Allowing the state-of-the-art sensor and microprocessor circuit to provide unsurpassed accuracy throughout the protractor’s 360°range.

The front panel buttons can be used to capture desired reading or to designate an alternate reference surface from which subsequent angles are then measured. The unit can also be easily recalibrated any available flat surface.

Technical data:

Resolution: 0.1°

Accuracy: 0° and 90° ≤ 0.1°; the rest ≤ 0.2°

Measuring Range: 4×90°(0~360°)

Working current : <100μA

Power: 3V CR2032 Lithium battery

Battery Life: more than 2000 hours

Feature:

1. ive shaft alignment and wheel alignment.

2. Rcraft flat calibration.

3. Tup of precision machines.

4. Ad or rail-track layout.

5. Tellite or aerial alignment.

6. Plastic shell

7.Aluminium frame work, four measuring surface

8 Large LCD

9. Direction symbol

10. ABS function to achieve absolutely measurement

Pack inf.

Accessory: 3V CR2032 Lithium battery, Instruction, leather pouch, bubble bag

Package: color box

Size of unit package: 160*70*74mm

Unit weight with package: 400g
