Angle Measuring Tool Digital Protractor Inclinometer Gauge

Angle Measuring Tool Digital Protractor Inclinometer Gauge photo-1
Angle Measuring Tool Digital Protractor Inclinometer Gauge photo-2
US$ 35 - 50 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangxi, China
Brand Name:
gemred
Model Number:
82210B-00
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou; Shanghai; Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangxi, China
Brand Name gemred
Model Number 82210B-00

 About Product

Angle Measuring Tool Digital Protractor Inclinometer Gauge is a revolutionary measuring tool to build 0.1° accuracy at vertical and horizontal planes and 0.2° accuracy at other angles. The aluminum frame with integral base-plate of this digital protractor is light, rigid and ultra-precise platform. Allowing the state-of-the-art sensor and microprocessor circuit to provide unsurpassed accuracy throughout 360° range. The unit can also be easily recalibrated to any available flat surface.



Applications of  digital protractor

² Automotive

Drive line Measurement

Wheel alignment

Frame straightening

² Industrial

Machine tool set up

Lathe and mill alignment

² Setup of precision machines

² Road or rail-track layout

² Satellite or aerial alignment

² Tool setting on Lathes

² Setting blade angle of Circular Saws

² Setting blade angle of Miter Saws

² Setting work piece angle for milling

² Platform monitoring

² Suitable for Built wood and metalwork projects

² Ensure wallpaper and cornices are level for decoration





Features of digital protractor

² Full range 360° measurement of this digital protractor allows you to work both horizontal and vertical planes

² Measuring range of 4 x 90° with ±0.1° repeatability

² Large and clear LCD display with 0.1° resolution

² Hold Reading function adopted in this digital protractor

² Simple self-calibration, calibrates the meter to any reference surface

² Display of this digital protractor remains upright enabling viewing at all angles

² High-impact, high-precision machined aluminum framework

² Fast and accurate measurement

² Compact & portable design

² Absolute and relative measurement conversion

²   3V Lithium battery lasts for 2000 hours in continuous use




Technical Data of digital protractor

Resolution

0.1°

Accuracy

0° and 90° ≤ 0.1°; the rest ≤ 0.2°

Measuring range

4×90°(0~360°)

Waterproof

IP54

Power

3V CR2032 Lithium battery

Battery Life

more than 2000 hours

Working current

<50μA

Weight

Approx 297g

Dimension

152*33.8*60mm





Package Inf. for digital protractor

 pacakge

 color box

 accessory

 3V CR2032 Lithium battery, ins 3V    CR2032 Lithium battery truction, leather  pouch, bubble bag

 size of unit package

 160*70*74mm

 unit weight with package

 430g

 unit size of product

 152*33.8*60mm





























 Angle Measuring Tool Digital Protractor Inclinometer GaugeAngle Measuring Tool Digital Protractor Inclinometer GaugeAngle Measuring Tool Digital Protractor Inclinometer Gauge





 Angle Measuring Tool Digital Protractor Inclinometer GaugeAngle Measuring Tool Digital Protractor Inclinometer Gauge
