auto laser level
1. Product certification
The products are complying with the requirements of CE(EMC),ROHS,PAHS.
Technical data:
| Resolution | 0.1° |
| Accuracy | 0° and 90° ≤ 0.1°; the rest ≤ 0.2° |
| Range | 4×90°(0°~360°) |
| Working current | <100μA |
| Work temperature | + 5°C~+50°C |
| Work humidity | ≤85%RH |
| Power | 3V CR2032 Lithium battery |
| Battery life: | more than 2000 hours |
Features:
Measuring range:0°~180.0°
Hold function to freeze measurements
Conversion between absolute measurement and relative measurement
Automatic shut off after 5 minutes
FUNCTION INSTRUCTION ON/OFF BUTTON In Shut off situation,simply press it to enter measurement mode and it will display the angle reading immediately, Now you can measure angle.Push this button again to shut it off. Under state to be measured,you press and hold it 6 seconds to turn it off. Under situation of OFF, type it to turn it on. When you turn it on again,the icon “--1--” appear, that means you need to recalibrate it. HOLD BUTTON
