About Product
digital spirit level meter with inclinometer
1. Product certification
The levelling instrument are complying with the requirements of CE(EMC),ROHS,PAHS.
2.Use range:
2.1 The floors, walls, doors, windows and glass curtain wall in construction, renovation and decoration industry can be measured and inspected the roughness, slope, level and vertical construction
2.2 The measurement, quality supervision and inspection of level, gradient, and inclination in water conservancy, road and bridge construction.
2.3 The measurement of communication facilities and antenna positioning.
2.4 The precision machinery manufacturing, industrial platform, device positioning, and the corresponding maintenance and upkeep in Industry, mining and military enterprises
2.5 The level and gradient of railway track construction inspection.
2.6 Others: oil exploration, drilling, fitness equipment, etc.
3. Features:
Main Features: Conversion between absolute measurement and relative measurement and inclination measurement. .
4. Mechanical Specifications
| Protection grade | IP50 |
| The length of work area | (total length-16) ±2mm |
| Electrical feature | EMC2 level |
| Sensitivity | 30 ±10 Points. |
| Angle error | 2mm/m |
| Maximum permissible error of zero | ±1.1mm |
| Stabilization time of bubble | less than 8s. |
| Distortion of ruler | =<1.2°/m |
5. Technical Data
| resolution | 0.1° |
| accuracy | 0° and 90° =< 0.1° ; the rest =< 0.2° |
| measuring range | 4 * 90° (0° -360° ) |
| working current | < 100μA |
| working temperature | +5° - +50° |
| working humidity | ≤85%RH |
| power | 3V (1.5V *2) Alkaline battery |
6. Pack Inf
| unit size of product | 600*22*57mm |
| unit weight of product | 655g ± 1.5g |
| accessory | 3V (1.5V *2) Alkaline battery; instruction |
| size of unit package | 650*75*40 mm |
| unit weight with package | 780g |
Company certification and honor
Production process
Applications and terminal
packing and delivery
