- With CE certificate for European market
- Euro III 36.8kW engine
- ISUZU 4x4 driving axles
- Electric control F2R2 transmission
- Comfortable cab with Air conditioner (Cold and heat)
- Single joystick pilot control
- Rear Camera Display (RVC)
- 0.65m3 bucket with auto level function and quick coupler device
Item | Specification | Item | Specification |
Kerb weight | 3670kg | Max. speed | 20km/h |
Rated bucket capacity | 0.65m³ | DRIVE AXLE |
|
Rated load | 1500kg | Main transmission type | Spiral gear, first stage deceleration |
Max. tractive force | 25kN | TYRE |
|
Max. breakout force | 25kN | Type specification | 11.00-16 |
Max. gradeability | 30% | Optional | 12.0-16.5; 14-17.5 |
Max. dumping height | 2645mm | STEERING SYSTEM |
|
Dumping distance | 976mm | Type | Articulated load-sensing hydraulic steering system |
Overall dimension(L*W*H) | 4709*1626*2645mm | Steering angle | 32° |
ENGINE |
| Min. turning radius | 4283mm |
Model | A498BT1 | HYDRAULIC SYSTEM |
|
Type | Inline, direct injection, water cooling | System working pressure | 28MPa |
Rated power | 36.8kW | Lifting time | 4.5s |
Rated speed | 2400r/min | Total time | 10s |
Optional | Cummins B3.3 | BRAKE SYSTEM |
|
Rated power | 45kW | Service brake | Air-over-hydraulic shoe-type |
TRANSMISSION SYSTEM |
| Parking brake | Manual disc brake type |
Hydraulic torque converter | Single-stage three-element hydraulic torque converter | FILL CAPACITY |
|
Type of gear box | Axis-fixed, double reduction | Fuel | 51L |
Gear shift | 2 forward shift, 2 reverse shift | Hydraulic oil | 68.6L |
