E0395 Haigint high pressure industrial water misting pump for Cooling Humidification Dedusting and Deodorization

High pressure industrial water misting pump for Cooling , Humidification, Dedusting and Deodorization

Haigint: http://mistingcooling.en.china.cn/productlist.html

Features of misting pump system

The misting pump can be applied for various functions, such as cooling ,humidfying, landscaping dedusting, lowering the temperature ,especiallly for chemical spraying and seed raising in the field of Agriculture  . The following is the distinguishing feature of the misting system:

Moist fog: The high pressure misting system can produce 5 billion droplets. the thread of the drop is 3~10um,which  looks  like mist covering mountain, forming water vapor and  targeting the excellent humidification and cooling effect .

Energy saving: Misting one kilogram water just need 6w electrical energy ,which consumes only 1/100 of the  traditional electric steam humidifier or the 1/10of the centrifugal humididfier.

Reliability: The high misting pump apply the newest technology into the process of producing . It can work for 24 hours sustainablely without destorying other parts like the misting nozzles ,fittings,and pipes,even in the air environment of high

concentrations of dust.

Environment health: The high pressure misting system use the non-circulatiuon water so that there is no threat of  the reproduction of bacteria.

Volume spraying: high  sprayer distribution and easily adjustable.

Pump specification

Photos	Item NO.	Flow(LPM)	Power	Voltage	Frequency	pressure(Bar)	Pressure(PSI)	size(cm)	weight(kg)
	HY- HPMP#1	0.2	0.12	100~240v	50/60HZ	60	900	38*18*24	4.5
	HY- HPMP#2	1	0.3	220/110v	50/60HZ	60	900	38*18*24	14.5
	HY- HPMP#3	2	0.75	220/110v	50/60HZ	60	900	47*25*32	23.5
	HY- HPMP#4	3	0.75	220/110v	50/60HZ	60	900	47*25*32	23.5
	HY- HPMP#5	7	1.8	220/110v	50/60HZ	60	900	70*36*3	41
large scale	HY- HPMP#6	8	1.5	380v	50HZ	70	1000	70*40*100	85
large scale	HY- HPMP#7	14	202	380v	50HZ	70	1000	70*40*100	90
large scale	HY- HPMP#8	18	3	380v	50HZ	70	1000	70*40*100	95

 The whole set of the equipment includes:

misting nozzle :  0.15mm,0.20mm,0.30mm,0.40mm,0.50mm

                             high pressure

                             Thread:10/24unc

                              washable filter

                              brasss with nickel plated

                              stainless steel orifice

misting fitting:

cross connector,slip-lock union,slip-lock male connector,slip-lock Tee connector,elbow connector,etc( 1/4",3/8",10/24unc)

tubing: nylon tubing and stainless steel tubing

tubing cutter,tubing clamp, filter,nozzle plug.

Application

1. Cooling

 Residential cooling, outdoor cooling, commercial place cooling

  2. Humidification

Industrial, agricultural and horticultural: green house, garden, livestock farming

 3. Dedusting and Deodorization

 Industry process, bulk powder, cement plant, foundry dust, fly ash control, waste transfer, recycling process

4. Insect Control

 garden or agriculture , kill the insect effenciently.
