Hand Power Hydraulic Master Pin Press for Track Link Group

Specifications

  Hand power hydraulic Master Pin Press for track link group

1.Professional excavator parts
2.High quality,Long-life
3.Unbeatable price
4.Hand powered hydraulic Master Pin Press for track link group

Handpowered Master Pin Press

Hand (power)hydraulic Master pin press clean up tjp of the hinge pin where the track link on front and back sides is disconnect before running .Hang up the draw bar and oil.Remove the fore-bolster from the rack to put the track link which is insertd by the draw bar from the top to bottom.adjust the  position of the rack by using the hanging --bolt to put the top side of the hinge pin into the bushing driver.then install the knocked-down bar.running the hand(power)pump to knock down the hinge pin.

SETUP AND OPERATION:

 Clean up the operating condition.Take debris object or impediments out
of operation area
Check the situation of connecting nnecting position of all pans
and tightness of the machine.
Check and prepare tools which are necessary

Specification

Pressure(t)

Travel(mm)

Match chain link type

LCZ5B

50

225

T175 T171 T135

M190 M175 M140 M135

LCZ6B

60

225

T203 T175 T171 T135

M203 M190 M175 M140

M135

LCZ10B

100

295

T228 T216 T203 T175

M228 M216 M203 M190

LCZ15B

150

325

T260 T228 T216 T203
