Specification:
Model | Working pressure (kgf/cm²) | Water flow(m³/h) | Range (m) | Main nozzle diameter | Interface size | Spray elevation angle |
PQ45-L80 | 5~8 | 46.6~92.3 | 45.5~62.8 | 18~26mm | 3"internal thread | 45° |
PQ40-F80 | 4~8 | 32.1~122.5 | 38.31~55.4 | 20~32mm | 3"Flange | 40° |
PQ45-L50 | 4~8 | 23.88~53.22 | 33~46.5 | 16~21mm | 2"External thread | 45° |
PQ40-L50 | 4~8 | 23.88~53.22 | 34.5~49.2 | 16~21mm | 2"External thread | 30° |
PQ30-L40 | 0.25~5 | 7.4~23.5 | 20~36.5 | 10~16mm | 1.5"External thread | 30 |
PQ30-L50 | 4~6 | 8~19 | 26~32 | 16~21mm | 2"External thread | 30° |
PQ30-L40 | 3~4.5 | 7.~11 | 20~28 | 10~16mm | 1.5"internal thread | 30° |
Features:
1, for large-scale agricultural irrigation;
2, for power plants, coal mines, ports, mines and other powdery material yard dust;
high jet elevation, conducive to water flow over the pile.
3,compact structure, high strength, reliable operation. Controllable angle.
4,high-quality aluminum alloy, lightweight smart, durable.
1) MOQ
1 UNIT
2) Spare Parts
The Easy-damage parts will be sent you together with the tractor. And in warranty period, if the spare part is not work
because of the quality, new parts will be sent to you for free
3) Shippment
We can help you arrange shippment
4) Delivery Time
One container:15-30 days.
5) Warranty Time
Completes service system, one year since arrival of destination port.
6) Payment Terms
T/T,30% deposit, 70 % balance against B/L copy ; L/C
7) Tractor Logo
We have our own logo, and we also can make your own logo in your order for free
8) Package and loading quantities
Nude Package:50 sets/40 HQ for mini tractor, 95 sets /40 HQ for walking tractor.
9) Implements
Mower, Plough, Trailer, Rotary tiller, or as your requirements.
10) Parts Supply
Complete parts Workshop, and can supply all parts.
For More Details, Pls Kindly Contact Me and I Will Answer You Within 24 hours!
