multi-purpose electric cheap farm walking tractor mini tractor
- 5000 Set / Sets per Month
- Qingdao
- T/T
You May Like
Product Details
| Condition | New | Type | Walking Tractor | |
| By wheel | 2WD | Usage | Farm Tractor | |
| Drive Type | Other, Belt transmision | Power(W) | 11K | |
| Certificate | Other, ISO | Brand Name | Guihua | |
| Model Number | LHW121-15HA | Place of Origin | Shandong, China | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Products Description
Engine
Type | Single cylinder, horizontal, 4-strokes, water-cooled |
Combustion system | Direct injection |
Bore×stroke | 100×115 |
Total Displacement | 0.903 |
Compression ratio | 16 |
1-hour rated output(kW/min) | 12.1/2200 |
12-hour rated output(kW/min) | 11/2200 |
Specific fuel consumption(g/kW.h) | ≤ 246.2 |
Specific lube oil consumption(g/kW.h) | ≤ 2.72 |
Cooling method | Hopper type Water-cooled or Radiator |
Lubrication method | Combined pressure and splash |
Starting method | Hand cranking or Key Start |
Net weight (kg) | 155/161/169/177/162 |
Overall dim (L×W×H) (mm) | 900*440*760 |
Certificate of Eninge:
Tractor frame:
| Model | LHW121-15H | ||||||
| Min. Clearance (mm) | 185 | ||||||
| Weight of Chassis (kg) | 360 | ||||||
| Weight in use (kg) | 505 | ||||||
| Speed of rotating shaft (rpm) | 188 | ||||||
| Dimension L*W*H (mm) | 2680*960*1250 | ||||||
| Number of blades (pcs) | 18 | ||||||
| Rotating width (mm) | 600mm | ||||||
| Type of tractor | Single axle, dual purpose for both traction & drive | ||||||
| Wheel tread (mm) | 800 | ||||||
| Min. turning radius (mm) | 900 without rotary tiller | ||||||
| Theoretical Speeds (km/h) | Rotation speed of Engine N=2200r/min | ||||||
| Forward | 1 | 2 | 3 | 4 | 5 | 6 | |
| 1.4 | 2.5 | 4.1 | 5.3 | 9.4 | 15.3 | ||
| Reverse | Ⅰ | Ⅱ | |||||
| 1.1 | 3.8 | ||||||
| Type of Clutch | Double Friction Flat of Constant Combination | ||||||
| Type of Steering gear | Meshing sleeve | ||||||
| Type of Brake | Disk | ||||||
| Belt | B1956 3 radix | ||||||
| Type of tire(Pa) | 6PR 6.00-12 (0.137-0.196) | ||||||
1. 18 months warranty since machine arrives destination port
2. The spare parts:
(1) We will send you the tool box for free.
(2) For the vulnerable parts, we can send you for free, During the warranty, owing to the quality problem, we will send the replacement for free.
3. T/T (Telegraphic transfer) payment: 30% as deposit, 70% balance payment shall be paid before delivery
4. delivery time: 20 working days after confirmation of deposit
5. Loading: LCL in iron crate
