Home > Products > milling inserts > Cemented Carbide Indexable Milling Cnc Tools Distributors
Cemented Carbide Indexable Milling Cnc Tools Distributors
- Chengdu/shanghai/shenzhen
- T/T D/P D/A Credit Card
You May Like
Product Details
Place of Origin | Sichuan, China | Brand Name | CDSanton | |
Model Number | CNE323 |
Product Description
Specifications
indexable milling cnc tools1. High quality with competitive price
2. tungsten carbide
3.Various types
indexable milling cnc tools
Advantages:
1.Made from 100% virgin raw material.
2.High quality with competitive price.
3.Dimensionally accurate, durable and reliable performance
4.Stable and best production ability.
5.factory direct products.
Grade:
YG6,YG8,YT15,ZP10,ZP20,ZK10UF,ZK20UF,etc
Type:
SNMG,SNMM,SNGN,SNMA,SNGA,SCMT,CNMG,CCMT,CCMW,CCMM,TNMG,TNMM,TNMA,TNGA,TCMT,TPGA,DCMT,DNMG,DNMM,DCMW,DNMA,etc
Coating:
VD,CVD,MT-CVD,coating also can be customer's requirement. All sizes with different chip-breaker.
Grade & Application:
Grade | Density(g/cm³) | TRS(n/mm²) | HRA | Performance & Applications |
ST2030 | 12.6 | 1950 | 91.5 | Rough turning,milling,planning and deep-drilling of carbon steel,cast steel,manganese steel ans alloy steel. |
ST2035 | 12.7 | 222 | 91 | A versatile grade, high red hardness,strength and resistance to impact and thermal shocking. Rough and strong cutting steel and cast steel. |
YT15 | 11.3 | 1560 | 92.5 | Semi-finishing of the medium chip section of steel, cast steel and alloy steel or small chip sections. |
YT5 | 12.9 | 2000 | 90.4 | Best strength and high impact & shock resistance, suit for rough turning and semi-finishing of carbon sttel and alloy steel(including forged steel parts,stamped parts and cast iron surfaces). |
YG6A | 14.9 | 1880 | 92.8 | High wear resistance & wear resistance. Semi-finishing of chilled cast irons, nonferrous metals & alloys;semi-finishing and finishing of hardened steel,alloy steel. |
YG813 | 14.4 | 2200 | 92 | Optimum wear resistance,high bending stength and high resistance to bonding. Machining of refractory alloys,stainless steel and high manganese steel,etc. |
YW1 | 13.4 | 1700 | 92.8 | High red hardness, resistant to impact load. A good grade for general purposes. Machining of ordinary steel,cast irons and hard to machine materials such as refractory steel,manganese sttel and stainless steel. |
YW2 | 13.3 | 1900 | 91.5 | High wear resistance, strength comparatively higher and resistant to high impact load. Roughing and medium machining of ordinary steel,cast irons as well as refractory steel, manganese steel, stainless steel and advanced alloy steel. |
Chengdu Santon cemented carbide Co.Ltd can supply our customers various types and grades of cemented carbides inserts including ISO turning inserts, Aluminum turning inserts, Profile turning inserts, Heavy turning inserts, Cermet inserts, PCBN&PCD inserts, Parting, Grooving inserts, Milling inserts and so on.Our inserts are optimized design with low wear, low friction and long life.
If you are interested in our products, please feel free to contact us. Your special design is also welcomed here.
Contact Us
- Chengdu Santon Cemented Carbide Co., Ltd.
- Contact nameJianchang Wang Chat Now
- Phone86-28-85839176
- AddressNo.2618, 4th Konggang Street, Southwest Airport Economic Development Zone, Chengdu City, Sichuan Province, P. R. China , Chengdu, Sichuan
