JST Connector and Servo Cables 1.2GHz Video Transmitter Harness
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Correa
Model Number:
TXC08
Payment & Shipping
Payment Methods:
Port of Shipment:
Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FPV 2.4G Skew Planar Aerial 2.4GHz Clover Leaf AntennaNegotiableMOQ: 1 Piece -
Adapter 90deg Right Angled SMA Male to RP-SMA FemaleNegotiableMOQ: 10 Pieces
-
Boating and Fishing CCTV Waterproof 12V Underwater Camera AnalogNegotiableMOQ: 1 Piece
-
Submersible Camera and LCD Recorder DivingNegotiableMOQ: 1 Set
-
High Quality 50M Deep Underwater Submarine Camera CCD 540TVL and LCD RecorderNegotiableMOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Correa
Model Number
TXC08
Specifications
JST Connector and Servo Cables 1.2GHz Video Transmitter Harness1) Compatible with our 900MHz, 1.2-1.3GHz, 2.4G Transmitters
This plug and play FPV cable harness offers easy connections for the folowing types of transmitters:
900MHz Video Tx
1.2-1.3GHz Video Tx
2.4GHz Video Tx
Instructions:
Plug the 4-Pin white connector with the transmitter and power supply through the JST cable. Please DO NOT connect more than 3S LiPo or DC 12V otherwise you will burn your devices.
Connector 1 (Video):
Brown: Ground
Red: +12V from the battery to the camera
Orange: Video signal from camera to the transmitter
Connector 2 (Audio):
Black: Ground
Red - +12V from the battery to the microphone
White: Audio signals
Connector 3 (Battery):
Red: Battery positive lead
Black: Battery negative lead
Connection Example:
