5.8GHz Wireless Receiver and Camera FPV Video Headset
Features:
- IPD adjustable
- Built-in wide angle front view camera
- Built-in dual-axis head tracking system
- High resolution: 854*480(WVGA), 1230K pixels
- High sensitivity 5 bands total 40 channels receiver
- Wide voltage supported: 7V-28V(2S-6S lipo battery)
Specifications:
- Dimensions: 168(L)x92.5(W)x41(H)mm(not including prominent part)
- Weight: 344g(not including carry case)
- Operating temperature: 0℃~+55℃
Binocular Display Specifications:
- FOV: 30 degrees(Diagonal)
- Resolution: 854x480(WVGA)
- Brightness: 350cd
- Interpupillary distance(IPD): 60-68mm adjustable
Wireless Receiver Specifications:
- ISM 5.8G 40CH
- Sensitivity: -90dBm±1dBm
- Antenna port: 2xSMA, 50ohm
- Video standard: NTSC/PAL
- Video output level: 1.0Vp-p Typ/75ohm
- Audio output level: 1.0Vp-p Typ/10Kohm
Front camera Specifications:
- FOV: 120 degrees(Diagonal)
- Resolution: 640x480(VGA)
- Focal length: f=0.95mm
- F/NO: F/NO=2.0
Head Tracker Specifications:
- Sensor: Magnetic, Inertial and gyro
- Output: PPM 8CH, optional 5-6CH, 5-7CH, 5-8CH, 6-7CH, 6-8CH, 7-8CH
AV Port Specifications:
- Div. AV OUT(3.5mm4P): Diversity video, audio output
- EAR OUT(3.5mm3P): 32Ω/75mW or 16Ω/105mW, with volume control
- AV IN(3.5mm4P): Video, audio inout
Pakcing List:
- 1*FPV Video Headset
- 2*Antenna
- 1*Futaba data cable
- 1*JR data cable
- 1*WFLY data cable
- 1*AV cable
- 1*Power cable
- 1*Carry case
Ready in stock and we ship within 1 working day after payment received.
* Enquiries will be replied within 1 working day.
* Fast samples arrangement and on time production.
* We accept payment methods include T/T, PayPal, Western Union,etc.
* All the products are aged and tested before shipment.
* Tracking information provided promptly.
Correa, is a professional manufacturer & exporter specialized in FPV Equipments including FPV Cameras, Wireless Tx Rx (5.8GHz, 1.2-1.3 GHz, 900MHz, 2.4GHz), FPV Monitors, FPV Antennas and RC Hobby Parts, etc.
With more than 8 years experience we are able to supply high quality FPV Equipments. Welcome to deal business with us!
