Full Hydraulic Movable Genertor Movable Power Station Movable Electric Power Truck
US$ 1,000 - 2,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
KTS
Model Number:
DZY80/100
Payment & Shipping
Payment Methods:
Port of Shipment:
Any Chinese Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CD MD HCD and HMD MODEL TYPE WIRE-ROPE ELECTRIC HOIST and HOUSE LIFTING EQUIPMENTUS$ 500 - 5,000MOQ: 1 Piece -
LD LX Single-Girder Electric Overhead Cranes Crane Hometown Safe Driving Brige CraneUS$ 500 - 10,000MOQ: 1 Piece
-
BCD BMD Type Explosive-Proof Electric Wire Rope Chain Remote Control HoistUS$ 1,000 - 10,000MOQ: 1 Piece
-
MH,MHB,MG,MC,MDG,MDC,MDZ TYPE Double Grider and Single Grider Semi Gantry CranesUS$ 10,000 - 100,000MOQ: 1 Set
-
LH LHB QD YH QZ QC QP QS YNQ Model Double-Girder Overhead CranesUS$ 1,000 - 200,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
KTS
Model Number
DZY80/100
Full Hydraulic Movable Genertor Movable Power Station Movable Electric Power Truck
Main Features:
Full Hydraulic Movable Generator can be used in all kinds of environments for pipeline anti-corrosion construction site,Adopts full hydraulic pressure drive technology,the use of foreign high-quality hydraulic components,capable of carrying electric welding machine, voltage machine and other equipment,it is to improve the technical level, replace foreign products the first choice of mobile power station.
1. Adopt cummins engine, equipped with a hydraulic telescoping, high reliability.
2.Hydraulic System main components adopt imported products.
3.Hydraulic command control, single lever operation.
4.The Vehicle traction, climbing ability is strong, brake is also very good.
5.Easy and convenient operation and easy maintenance.
TECHNICAL SPECIFICATIONS
| DZY80/100 Full Hydraulic Movable Generator | |||
| Machine No. | DZY80 | DZY100 | |
| Boundary Dimension (LengthXWidthXHeight) mm | 5415X2370X2955 | 5415X2370X2955 | |
| Machine Weight (kg) | 9695 | 9695 | |
| Ground Pressure (kpa) | 28.5 | 28.7 | |
| Additional Traction (kn) | 91 | ||
| Climbing Angle | 25° | ||
| Travel Speed (km/h) | Double Speed Change, I :0-2.9; II:0-4.6 | ||
| The minimum Clearence from the ground (mm) | 570 | ||
| The length of track shoe on the ground (mm) | 2755 | ||
| Pitch (mm) | 1770 | ||
| Track Shoe | Pitch:171.45mm, Width:600mm, triple grouse | ||
| Approach Angle | 34° | ||
| Departure Angle | 35° | ||
| Engine | Model | Cummins 6BTA5.9-C170 | Cummins 6BTA5.9-C180 |
| The minimum fuel consumption rate (g/kw.h) | 208 | 206 | |
| Rated Power (KW) | 125 | 132 | |
| Generator | Model | Stanford UCI274C | Stanford UCI274E |
| The rated Voltage | 380/220V | 380/220V | |
| The rated frequency | 50Hz | 50Hz | |
| The rated capacity (KVA)/Power (KW) | 100KVA/(80KW) | 125KVA/(100KW) | |
| The Hydraulic Lift (3T) | Luffing Angle (°C) | 1-65 | |
| Largest Crane Hoisting Moment | 6.4t*m | ||
| Maximum lifting height(m) | 6.1 | ||
| Maximum working height(m) | 5.6 | ||
| Rotary form | 360° | ||
| Electrical Control Cabinet | Electric leakage protection | YES | |
| Exterbal plug number | 380V-2PCS,10KW: 220V-2PCS,2.2KW | ||
