Excavator long reach boom&arm/two-segment type long reach boom for excavator

Specifications

Excavator long reach boom
1.Suitable for 10~350 ton excavator
2.warranty time: 12 months
3HIgh quality with competive pric





Long Reach for Excavator:

1. Original excavator performance;

2. Made of high strength steel plate;

3.Improves operation scope;

4.Operation extent 13m-24m;

5.Convenient for existing excavator installation;



Model	KTS120	KTS200	KTS220	KTS300	KTS350	KTS400	KTS450
Length of long reach (mm)	13000	15380	15380	18000	20000	22000	24000
Weight (kg)	3000	4000	4200	5200	6000	6500	7000
Capacity	0.3	0.4	0.4	0.4	0.5	0.6	0.6
Maximum digging deepness (mm)	9000	11340	11370	13000	15000	16500	18000
Maximum extensive scope (mm)	12500	15100	15100	17600	19600	21600	23600
Maximum digging height (mm)	11300	12510	12610	13720	14920	16100	17300
Folding height (mm)	2900	2980	3040	3210	3210	3400	3400
Suitable Excavator tonnage (ton)	12	20	22	30	35	40	45



Long Reaches are used for desilting rivers and excavating for port construction, railway construction and groundwork construction with extensive operation scope, high efficiency and high security.
