Deadend Hardware Overhead line Straight bolted guy clamp made of hot rolled bar by stamping
- Guy clamp with three 5/8" diameter bolts.
- Clamp is 4" long.
- Parallel grooves trap strand tightly without marring.
- Each bolt has a shoulder to prevent turning while tightening.
- Hot dip galvanized.
APPLICATION:
Parallel grooves trap strand tightly without marring. Plate halves align evenly for easy application. Each bolt has a shoulder to prevent turning while tightening.
Features straight parallel grooves for greater clamping area without damage to guy strand. Bolts have shoulders to prevent turning when nut is tightened. Alternate bolts are reversed for wrench clearance.
Main specifications for our guy clamp:
TYPE | Length | Width | Product Finish | Material | Note | Weight | Accommodates |
Offset 6409 | 3 1/4" | 1 1/2" | Galvanized, ASTM A-153 | Steel | Two 1/2" Carriage Clamping Bolts | 1.32 lbs | 3/16" to 5/16" |
Offset 6410 | 4" (102 mm) | 1 5/8" | Galvanized, ASTM A-153 | Steel | Two 5/8" Carriage Clamping Bolts | 1.69 lbs | 5/16" to 1/2" |
Straight 6448 | 3 3/8" | 1 9/16" | Galvanized, ASTM A-153 | Steel | Two 1/2" Carriage Clamping Bolts | 1.18 lbs | 1/4" to 7/16" |
Straight 6449 | 4" (102 mm) | 1 9/16" | Galvanized, ASTM A-153 | Steel | Three 1/2" Carriage Clamping Bolts | 1.59 lbs | 1/4" to 7/16" |
Straight 6450 | 6" (152 mm) | 1 9/16" | Galvanized, ASTM A-153 | Steel | Three 1/2" Carriage Clamping Bolts | 2.12 lbs | 1/4" to 7/16" |
Straight 6460 | 6" (152 mm) | 2 1/8" | Galvanized, ASTM A-153 | Steel | Three 5/8" Carriage Clamping Bolts | 4.05 LBS | 3/8" to 5/8" |
Straight 6461 | 6" (152 mm) | 1-21/32" | Galvanized, ASTM A-153 | Steel | Three 5/8" Carriage Clamping Bolts | 2.4 lbs | 5/16" to 1/2" |
Straight 6462 | 4" (102 mm) | 1 21/32" | Galvanized, ASTM A-153 | Steel | Two 5/8" Carriage Clamping Bolts | 1.74 lbs | 5/16" to 1/2" |
Strait 7901 | 2 1/2" |
| Galvanized, ASTM A-153 | Steel | 5/8" Mounting Bolt | 0.66 lbs | 1/4" to 7/16" |
Angled 7902L | 7" (178 mm) |
| Galvanized, ASTM A-153 | Steel | 5/8" Mounting Bolt | 2 lbs | 1/4" to 7/16" |
Angled 7902R | 7" (178 mm) |
| Galvanized, ASTM A-153 | Steel | 3/4" Mounting Bolt | 1.97 lbs | 1/4" to 7/16" |
Strait 7903 | 5 3/4" |
| Galvanized, ASTM A-153 | Steel | 5/8" Mounting Bolt | 1.83 lbs | 1/4" to 7/16" |
Strait 7903L | 5 3/4" |
| Galvanized, ASTM A-153 | Steel | 5/8" Mounting Bolt | 1.57 lbs | 1/4" to 7/16" |
Angled 7904 | 5 3/4" |
| Galvanized, ASTM A-153 | Steel | 3/4" Mounting Bolt | 1.74 lbs | 1/4" to 7/16" |
