Supply Radial Load F4-9M Miniature Thrust Ball Plane Bearings
US$ 0.08 - 20
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
YWS or customer's brand
Bore Size:
10, 150
Outside Diameter:
24, 215
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Small Diameter F9-20M Thrust Ball Bearings 9X20X7 mm for PumpsUS$ 0.08 - 20MOQ: 100 Pieces -
F5-11M F5-12M Thrust Ball BearingUS$ 0.1 - 0.5MOQ: 10 Pieces
-
2013 Hot Sale Thrust Ball Bearing 51308US$ 0.1 - 10MOQ: 10 Pieces
-
Chrome Steel F8-16M F8-19M Thrust Ball Bearings for PumpsUS$ 0.08 - 20MOQ: 100 Pieces
-
High Precision Bearing 51205 Thrust Ball Bearing 51180mUS$ 1 - 10MOQ: 10 Pieces
Brand Name
YWS or customer's brand
Bore Size
10, 150
Outside Diameter
24, 215
Model Number
F4-9M
Precision Rating
P0/P2/P4/P5/P6
Seals Type
open/zz /rs/2rs
Number of Row
Single Row
Place of Origin
Shandong, China
Supply Radial load F4-9M Miniature thrust ball plane bearings
1.Description of F4-9M Miniature thrust ball plane bearings
ID: 4 mm OD:9 mm H: 4 mm
Thrust ball bearings with the contact angle of 90 degrees can only bear axial load with low speed limit. The single direction thrust ball bearings of SS51000 series can only bear axial load in one direction and can limit the axial move o the bearings and the outer cover in one direction with outer cover.
| Limiting soeed | ball | ||||||||||
| ModelNo. | d | D | d1 | D1 | H | Cr(N) | Cor(N) | rpm | |||
| Grease | Oil | number | diameter | ||||||||
| F3-8M | 3 | 8 | 3.2 | 7.8 | 3.5 | 600 | 480 | 11000 | 15000 | 6 | 1.588 |
| F4-9M | 4 | 9 | 4.2 | 8.8 | 4 | 800 | 520 | 8000 | 12000 | 6 | 1.588 |
| F4-10M | 4 | 10 | 4.2 | 9.8 | 4 | 658 | 580 | 6000 | 10000 | 6 | 1.588 |
| F5-10M | 5 | 10 | 5.2 | 9.8 | 4 | 950 | 830 | 5100 | 8100 | 7 | 1.588 |
| F5-11M | 5 | 11 | 5.2 | 10.8 | 4.5 | 988 | 880 | 5000 | 8000 | 7 | 1.588 |
| F5-12M | 5 | 12 | 5.2 | 11.8 | 4 | 988 | 880 | 5000 | 8000 | 7 | 1.588 |
| F6-12M | 6 | 12 | 6.2 | 11.8 | 4.5 | 1600 | 1255 | 5000 | 7000 | 8 | 2 |
| F6-14M | 6 | 14 | 6.25 | 13.8 | 5 | 1800 | 1588 | 4000 | 7000 | 8 | 2.381 |
| F7-13M | 7 | 13 | 7.2 | 16.8 | 4.5 | 1422 | 1255 | 4000 | 7000 | 9 | 2 |
| F7-15M | 7 | 15 | 7.2 | 14.8 | 5 | 2200 | 2000 | 3600 | 7100 | 8 | 2.5 |
| F7-17M | 7 | 17 | 7.2 | 16.8 | 6 | 2600 | 2256 | 3500 | 7000 | 8 | 2.381 |
| F8-16M | 8 | 16 | 8.2 | 15.8 | 5 | 2500 | 3000 | 4000 | 8000 | 9 | 3 |
| F8-19M | 8 | 19 | 8.2 | 18.8 | 7 | 3452 | 3000 | 3000 | 5000 | 8 | 3.175 |
| F9-20M | 9 | 20 | 9.2 | 19.8 | 7 | 3356 | 2999 | 2500 | 4500 | 8 | 3.175 |
| F10-18M | 10 | 18 | 10.2 | 17.8 | 5.5 | 2230 | 2721 | 2500 | 4500 | 10 | 2.381 |
2.Photos of F4-9M Miniature thrust ball plane bearings
3.Production Process & 100% inspection during production.
4. 30% Sampling before delivery
5.Packing Pictures:
6. Shipment
if you need, please feel free to contact me. Thanks!
