| Model number | 51105 | |
| Dimension (mm) | Bore(d) | 25 |
| Outer Diameter( D) | 42 | |
| Width (B) | 11 | |
| Weight(kg) | 0.059 | |
| Material | stainless steel/chrome stee/ceramic | |
| Precision | P0, P6,P5,P4 | |
| Vibration | Z1V1,Z2V2,Z3V3 | |
| Seals type | open,ZZ,2RS | |
| Clearance | C2,C0,C3,C4,C5 | |
| Load rating(KN) | Dynamic Cr: | 19.5 |
| Static Cor: | 37.2 | |
| Limiting Rotate | Grease: | 4400 |
| Speed(r/min) | Oil: | 6800 |
| Quality standard | ISO9001 | |
| Service | YWS or OEM | |
| Delivery Time | 5-30days | |
| Payment Term | 100% T/T ; 30% T/T as deposit,70% balance payment | |
| by T/T before shipment; L/C at sight | ||
| Installation Guide | 1. Clean bearings and related components; | |
| 2. Check the size of connected components; | ||
| 3. Installation; | ||
| 4. Inspection of the bearings after installed; | ||
| 5. Supply lubricant periodically. | ||
More specification of thrust ball bearing
1. Single direction thrust ball bearings: consist of two washers with raceways and balls guided b a cage. Washers have flat seating surfaces, and that is why they must be supported so that all balls can be evenly loaded. Bearings carry the axial load only in one direction. They are not able to carry radial forces.
2. Double direction thrust ball bearings: have two cages with balls between the central shaft washer and two houding washers with flat seating surfaces. The shaft washer has raceways on both sides and is fixed on the journal. Bearings are able to carry only axial forces in both directions.
3.These bearing are widely used in automobile, electrical. (Home appliances, electric tools, fitness equipment, motors, medical devices, motorbikes, textile machines)
Model no. we can manufacture
items |
|
|
|
| ||||
mm | (kN) | (kN) | rpm | Kg | ||||
d | D | T | Cr | Cor | Grease | oil |
| |
51103 | 17 | 30 | 9 | 10.8 | 18.2 | 5,300 | 7,500 | 0.024 |
51104 | 20 | 35 | 10 | 14.2 | 24.5 | 4,800 | 6,700 | 0.036 |
51105 | 25 | 42 | 11 | 15.2 | 30.2 | 4,300 | 6,000 | 0.055 |
51106 | 30 | 47 | 11 | 16 | 34.2 | 4,000 | 5,600 | 0.062 |
51107 | 35 | 52 | 12 | 18.2 | 41.5 | 3,800 | 5,300 | 0.077 |
51108 | 40 | 60 | 13 | 26.8 | 62.8 | 3,400 | 4,800 | 0.11 |
51109 | 45 | 65 | 14 | 27 | 66 | 3,200 | 4,500 | 0.14 |
51110 | 50 | 70 | 14 | 27.2 | 69.2 | 3,000 | 4,300 | 0.15 |
51111 | 55 | 78 | 16 | 33.8 | 89.2 | 2,800 | 4,000 | 0.22 |
51112 | 60 | 85 | 17 | 40.2 | 108 | 2,600 | 3,800 | 0.27 |
51113 | 65 | 90 | 18 | 40.5 | 112 | 2,400 | 3,600 | 0.31 |
51114 | 70 | 95 | 18 | 40.8 | 115 | 2,200 | 3,400 | 0.33 |
51115 | 75 | 100 | 19 | 48.2 | 140 | 2,000 | 3,200 | 0.38 |
51116 | 80 | 105 | 19 | 48.5 | 145 | 1,900 | 3,000 | 0.4 |
Workflow
Certification
1.Neutral Packing: White Plastic bag / Outer Carton / Pallet
2.Yuki Brand packing: YWS Plastic bag/YWS outer carton/Pallet
3.Outer Carton Size:39.5cm*26cm*21.5cm or 39.5cm*26cm*17cm
4.Pallet Size:80cm*120cm*80cm or 120cm*80cm*100cm
1. Your inquiry will be reply within 2 hours.
2.Packing: you will receive a Perfect product with strong outside packing.
3. With advanced first-level facilities and testing equipment,to insure no mistake on the dimension of the bearings.
4. Return Policy:
We gladly accept returns for item purchased within a 30 day period, provided it is still in the original package, not used nor damaged.
5. Warranty Claims :
The Warranty covers any Defect of the product for a period of 12 months. It does not cover items that are not correctly installed or over tightened which may cause premature failure. Installation or any other fee's are not refundable.
Q: What are the main factors to consider when choosing which type of bearings?
A: Bearing load, bearing speed, bearing performance and mounting and dismounting of bearings.
Q: Where is your port of shipment located?
A:Our main port of shipmentisQingdao port, and we may operate at other port if required by the customer.
Q: What are common Lubrication?
A: Lubricating bearings used in two ways: oil lubrication and grease lubrication. In addition, there are also solid lubricant .
Q: Do you like to serve the client only with the small orders?
A:We enjoy to grow up together with all our clients whatever big or small.You will become bigger and bigger to be with us.
