Home > Products > Sprayer > 2016 hot sale agricultural sprayer and Agricultural Pesticide Sprayer for America market
2016 hot sale agricultural sprayer and Agricultural Pesticide Sprayer for America market
- 20 Set / Sets per Month
- QINGDAO
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | GWW | Model Number: | GWW 3920 |
Sprayer Type: | Pump | Diameter: | 1800 cm | Feature: | High Efficient |
Condition: | New | After-sales Service Provided: | Overseas service center available |
Product Description
2016 hot sale agricultural sprayer and Agricultural Pesticide Sprayer for America market
Product Introduction:
This kind of sprayers includes 9 models (3920,3920A,3920B,3920C,3920D,3920E,3920F,3920G,3920H), divided into 2 classes : One is self-propelled sprayer model 3920 and the other is trailed sprayer which includes hydraulic lifting and folding type and manual one; customers can choose different sprayer model according to the demands of chemical tank, spraying span, plot sizes, and tractors.
Big capacity chemical tank can reduce times of adding water and chemical
Long working time, high efficiency; adjustable wheel track reduces the loss of seedlings; Stable and balanced structure.
Advanced combination valve with multiple functions of pressure adjustment, direction changing, sectional control and filtration
Stable pressure, reliable
Mixture method is high-pressure jet and reflux which ensures even liquid and effective pest control.
Optional variable spray system to achieve accurate and efficient working
Main body is made of manganese steel
High performance and suspension balance system.
Chemical tank capacity(L) | 2000,3000(optional) |
Tank material | Fiberglass |
Lifting and folding | Manual and hydraulic |
Spraying span(m) | 12-16(manual),18-25(hydraulic) |
Spraying angle(°) | 110 |
Transportation dimension(mm) | 4500×2400×2700 (3920B) 4580×3230×2900 (3920E) 5150×2760×2660 (3920F) |
Weight(kg) | 1300-1400 (3920E) 1450-1680(3920F) |
Membrane pump discharging volume(L/min) | 105,210,185 |
Max rotation speed(rpm) | 540 |
Max pressure of pump(mpa) | 1.5-2 |
Working pressure(mpa) | 0.3-0.5 |
Matched power(hp) | 60-200 (Tractor weight is not lower than 5000kg, with hydraulic control) |
Filter mesh number (mesh) | 25-60 |
Filtering grade | 4 grade |
Working efficiency | 120-160mu/h, 8-11ha/h, 3920A 50-80mu/h, 3-5.4ha/h |
Mixture model | High pressure jet and reflux mixing |
Nozzle | Original imported |
SHANDONG GROUPWORKWIN CO., LTD. is a company specializes in supplying the best farm equipment and garden equipment, and all our products are competitive quality and price. Our aim in recent 10 years is that we will be the most advanced China farm mechanical company, and make all the customers satisfied is our final goal.
Our service includes: sale of equipment, accessories, tool maintenance and training. Our have a very big and wide sale branch chain, and we can supply complete service and products chain. In this way, we can supply farm equipment and after sale service to the customers all over the world.
Our mission:
Developing new customers and maintaining relationship with existing customers and strengthening the relationships between the customers and us; working more than expected; supplying the equipment of high quality and high function all over the world, working better for the customers and win their trust.
Our products:
Cultivated land equipment: tractor, rotary tiller, micro tiller, walking tractor
Planting equipment: rice trans planter,agricultural equipment for fertilizing machine, Hot sale maize seeder with fertliser bins
Plant protection equipment: sprayer, Atomizer, lawn mower
Harvesting equipment: Combine harvester, corn Sheller; Peanut Sheller;
Vegetables and grains driers.
Q1: Are you a manufacturer or a trading company?
A1: We are 100% manufacturer. We have 20 years producing experience. We are one of leading manufacturers for kinds of agricultural equipments with many new production lines.
Q2: What about the payment terms?
A2: T/T, L/C, PayPal, Western Union are accepted, and it is also flexible according to different sets of machines.
Q3: What is the delivery time?
A3: It depends on the quantity of the products. Generally we can arrange shipment after 7 to 15 working days.
Q4: What is the MOQ?
A4: Normally the MOQ is one set. There are some exceptions to this requirement because of the type of machines.
Q5: What warranty do you offer?
A5: 12 months warranty from the time of the goods arrival at destination. It is also could be longer for some parts of the machine.
Q6: About the package:
A6: Iron frame or iron frame box. We try to save a space, and ensure easy installation after the arrival of the goods, and customized package is acceptable.
Q7: Can I put my brand name on your agri machines instead of your brand name?
A7: Yes. We could do OEM/OBM.
Q8: Can I get a full price list for these products
A8: Yes, please ask our sale consultants for the product catalogue.
Q9:- Can we mix different models together?
A9: Our products includes tractors, rotary tillers, mini tillers, rice planters, wheat planters, sprayers, atomizers, lawn mowers and so on, you may mix different products or models in 1x20ft or 1x40ft container but in order to make the best use of container room, usually we advise you to check the size of the machines.
Q10: - Can I get an exclusive right for your agri machines in some territories?
A10: We can grant the exclusive agent for all of our agri machines in one country market.
