Specifications:
1. Good quality pto driven tractor road sweeper of tractor parts used garden tractor lawn mower
2. All parts are forged.
3. Sample welcome
4..LOW MOQ
Features:
1.Model Number/Cross Series: | T01,T02,T03,T04,T05,T06,T07,T08 and some special cross Journal |
2. Dimension/Size: | Minimum overall length: 600-1800mm or 27"-60" |
3. Working Condition: | For Tractors, Trucks and Agricultural Use |
4. Shield Colour: | Yellow or black |
5. Material: | Steel and Plastic |
6. Tube: | Triangular, Lemon, Star and Splined |
7. Apply | Tractor, Rotary Cultivator, Planter Machine ,Farm and etc. |
8. Certificate | CE Certificate |
PTO shaft structure:
Technical data:
Item | Cross journal size | 540dak-rpm | 1000dak-rpm | |||
Series 1 | 22mm | 54mm | 12KW | 16HP | 18KW | 25HP |
Series 2 | 23.8mm | 61.3mm | 15KW | 21HP | 23KW | 31HP |
Series 3 | 27mm | 70mm | 26KW | 35HP | 40KW | 55HP |
Series 4 | 27mm | 74.6mm | 26KW | 35HP | 40KW | 55HP |
Series 5 | 30.2mm | 80mm | 35KW | 47HP | 54KW | 74HP |
Series 6 | 30.2mm | 92mm | 47KW | 64HP | 74KW | 100HP |
Series 7 | 30.2mm | 106.5mm | 55KW | 75HP | 87KW | 18HP |
Series 8 | 35mm | 106.5mm | 70KW | 95HP | 110KW | 150HP |
Series38 | 38mm | 102mm | 70KW | 95HP | 110KW | 150HP |
Product advantages:
1.All parts are forged.
2. Use vertical broacher machine,this will produce good centric degree.
3. Plastic cover can work normally between -35 °C to 80 °C .
4. All torque limiter are torque set ready before transportation.
5. The highest power transmission can reach 200HP (series 48).
PTO shaft structure:
Other relevant parts for cars or machinery we have made in our workshop are as follows:
Drive shaft parts and assemblies,
Universal joint parts and assemblies,
PTO drive shafts,
Spline shafts,
Slip yokes,
Weld yokes,
Flange yokes,
Steering columns,
Connecting rods,
etc.
Welcome to visit our factory!
| tractor spare parts in Stock | |
| tractor rim | gears |
| kit coupling | bearing |
| steering wheel | tractor link hitch |
| PTO shaft | tractor sealing KB-TX |
| tractor blades | lamps |
| tractor hitch YM F14/F15 | link hitch |
| tyre | sealing |
| gasket | light |
| air filter | tractor hub |
| filter element | brake shoes |
| air strainer element | calande |
| air filter cartridge | hitch |
| cardan | tractor ignition key |
| tractor water pipe | klaxon |
| disc clutch KB-TX | mass tractor |
| counter | battery cap |
| clutch | ratchet wheel |
| tractor bulb | oil pressor |
| tractor light | radiator cap |
| exhaust collector | tractor regulator |
| Tractor keys | stickers |
| gasket | light |
| tractor blades | lamps |
Why Speedway?
1. Customized and designed according to the customers' sample, drawing or requirements.
2. Following the customers' requirements or as our usual packing
3. Customer-First, Price-Competitive, Quality- High, Services- Professional.
4. Flexible minimum order quantity
For more information about us, contact us right away.
Packing detail:
each product will be packed in individual box with label of all information on it, and boxes will be packed in carton, cartons will be packed in wooden cases. Heavy parts, light parts and fragile parts will be packed separately
Delivery Detail:
30-35 days for sea order based on containers.
Q1: Can I buy one of your products for Sample?
A: Yes, we can provide you sample, and will send you by DHL or according to your requirements, or find the cheapest forwards for you.
Q2: How could I know if the product suitable for my machine or not?
A: Pls tell us which product you are interested in, We will give you the main sizes, or you can provide your drawings or samples, we will make according to your drawings.
Q3: I want to find a supplier for my new products, can you help me ?
A: Yes, kindly offer us your drawings or samples. We will quote you the cost.
Q4: How long for your to make a new products?
A: Usually 20-35days for the drawing ones and 35-60 days for the sampled ones.
Q5: What is the payment method?
A: Our payment method: T/T, WEST UNION, PAYPAL.
Q6: How is the quality?
A: Strict control before shipment.
Q7: What are our major market?
A: Our main markets are Middle east, Africa, Southeast Asia and South America, European…
